| . . | 24100J7421F1 | [1] | PANEL ASSY, INST | |
| 1. | 2416P9608 | [1] | PANEL, INSTRUMENT | |
| 2. | 2416N3723 | [1] | | |
| 3. | 2416P9609 | [1] | BRACKET | |
| 4. | 2416N3777 | [1] | PANEL, INSTRUMENT | |
| 5. | 2416J1050 | [1] | BRACKET | |
| 6. | 2414P4555 | [1] | COVER | |
| 7. | 2414T3232 | [1] | COVER | |
| 8. | 2479U534F1 | [1] | GAUGE, CLUSTER SEE FIG.07-013 | GAUGE, CLUSTER SEE FIG.07-013 |
| 9. | 2489U183 | [1] | FUEL GAUGE | KOB |
| 14. | 2479U229 | [3] | RELAY | KOBSWITCH |
| 15. | 2479Z495 | [1] | CONTROL | KOBTERMINAL |
| 16. | 2479R243F1 | [1] | FUSE BOX | KOB |
| 16-3. | 2479R243S1 | [7] | FUSE | KOB15 Amp |
| 17. | 24100N3655F1 | [1] | LEVER ASSY, THROTTLE | |
| 17-1. | 2416P9564 | [1] | BRACKET | |
| 17-2. | 2406P3295 | [2] | LEVER | |
| 17-3. | 2406T971 | [2] | GRIP | KOB |
| 17-4. | 2418T13641 | [1] | SPACER | |
| 17-5. | 2418T5131 | [1] | WASHER | |
| 17-6. | R16T0040 | [1] | WASHER | KOB Superseded by part number: 2418T12345, 77266155 |
| 17-7. | R16T0137D2 | [4] | WASHER | KOBCone Disk Spring -- ID 12.2 x OD 25 x Th 1.6mm |
| 17-8. | 2420T2634 | [1] | CAPSCREW | |
| 17-9. | ZN21C12015 | [1] | NUT | |
| 17-10. | ZN11C08007 | [1] | NUT | KOBM08x1.25mm Superseded by part number: ZN16C08007 |
| 17-11. | ZP15D03025 | [1] | COTTER PIN | KOB Superseded by part number: ZP15D03035 |
| 18. | 2430U144D8F1 | [1] | CABLE | KOB |
| 18-4. | R06T0042D1 | [1] | END | KOB |
| 18-5. | B19T0175 | [1] | PIN | KOB |
| 18-6. | ZP15K01210 | [1] | LOCK PIN | KOBCOTTER-PIN |
| 19. | 2430U144D9F1 | [1] | CABLE | KOB |
| 19-4. | R06T0042D1 | [1] | END | KOB |
| 19-5. | B19T0175 | [1] | PIN | KOB |
| 19-6. | ZP15K01210 | [1] | LOCK PIN | KOBCOTTER |
| 20. | 2479Z214 | [1] | CIGARETTE LIGHTER | KOB |
| 21. | 2479Z494D1 | [2] | SWITCH | KOB |
| 22. | 2479R676 | [1] | SWITCH | KOB |
| 23. | R79T0001 | [1] | SWITCH | KOBSWITCH,WIPER |
| 24. | R16T0402D1 | [2] | CLAMP | KOB |
| 25. | R16T0063D4 | [1] | GROMMET | KOB |
| 26. | 2420R429D15 | [2] | GROMMET | KOB |
| 27. | 2420Z699 | [4] | GROMMET | KOB |
| 28. | ZS16C12030 | [2] | CAPSCREW M12x1.75x30mm | CAPSCREW M12x1.75x30mm |
| 29. | ZM11C10025 | [6] | BOLT | KOBM10x1.50x25mm (Incls. Lockwasher) Superseded by part number: ZM12C10025 |
| 30. | ZM11C08020 | [31] | BOLT | KOBM08x1.25x20mm (Incls. Lockwasher) Superseded by part number: ZM12C08020 |
| 31. | ZM11C06014 | [8] | SCREW | KOB |
| 32. | ZS31C06012 | [14] | SCREW,Phillips Drive, Pan HD, M6 x 12mm | KOBM06x1.0x12mm |
| 33. | ZS31C05016 | [2] | BOLT,Phillips Drive, Pan HD, M5 x 16mm | KOBM05x0.8x16mm |
| 34. | ZS31C05012 | [10] | BOLT,Phillips Drive, Pan HD, M5 x 12mm | KOBM05x0.8x12mm |
| 35. | ZS31C04040 | [2] | SCREW,Phillips Drive, Pan HD, M4 x 40mm | KOBM04x0.7x40mm |
| 36. | ZS41C06025 | [4] | SCREW,M6 x 25mm | KOBM06x1.0x25mm |
| 37. | ZW16X10000 | [6] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
| 38. | ZW16X06000 | [19] | WASHER | KOBID 06 x OD 12.5 x Th 1.6mm Superseded by part number: 86588450 |
| 39. | ZW16X05000 | [2] | WASHER | KOB |
| 40. | ZW26X12000 | [2] | LOCK WASHER | KOBID 12 x OD 21 x Th 3.0mm |
| 41. | ZW26X06000 | [11] | LOCK WASHER | KOBID 06 x OD 07 x Th 1.5mm |
| 42. | ZW26X05000 | [12] | LOCK WASHER | KOBLock -- ID 05 x OD 09 x Th 1.3mm |
| 43. | ZW26X04000 | [2] | LOCK WASHER | KOBID 04 x OD 7.6 x Th 1.0mm |
| 44. | ZN16C06005 | [11] | NUT | KOBM06x1.0mm Superseded by part number: ZN18C06005 |
| 45. | ZN16C04003 | [2] | NUT | KOBM04x0.7mm Superseded by part number: ZN18C04003 |
| 46. | ZW26K06000 | [14] | LOCK WASHER | KOBID 06 x OD 11 x Th 1.5mm |
| 47. | 2416P9730 | [1] | BRACKET | |
| 48. | 2489U184 | [2] | OIL PRESSURE GAUGE | KOB |
| 49. | ZM11C10020 | [4] | SCREW | KOBM10x1.50x20mm (Incls. Lockwasher) Superseded by part number: ZM12C10020 |
| 50. | 2418T537302 | [4] | WASHER | |
| 51. | ZW16X08000 | [1] | WASHER,8mm ID x 17mm OD x 1.6mm Thk | KOBID 08 x OD 17 x Th 1.6mm |
| . . | 24100J7421F2 | [1] | PANEL ASSY, 1NST, Start Serial: LU.0127- | |
| 52. | 2416P11481 | [1] | BRACKET | |
