神钢零件查询(K935) - EXCAVATOR SUPPLEMENT ASN LU00154 (1/76-12/03) (07-013) - GAUGE, CLUSTER (FOR NORWAY) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
823 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2479U534F1 | [1] | GAUGE, CLUSTER (FOR NORWAY) | GAUGE, CLUSTER (FOR NORWAY) |
| . . | 2479U534S1 | [1] | PARTS | |
| 2. | 2479U534S2 | [1] | COVER, FRONT | |
| 3. | 2479U534S3 | [11] | PLATE | |
| 4. | 2479U534S4 | [1] | LENS | |
| 7. | 2479U534S7 | [11] | SOCKET | KOBSOCKET |
| 8. | 2479U534S8 | [3] | SOCKET | KOBSOCKET |
| 9. | 2479U534S9 | [3] | SCREW | |
| 10. | 2479U534S10 | [15] | WASHER,PLAIN | |
| 11. | 2479U534S11 | [15] | WASHER, SPRING | |
| 12. | 2479U534S12 | [15] | NUT | |
| 14. | 2479U534S14 | [1] | HOUR-METER | HOUR-METER |
| 15. | 2479U534S15 | [2] | INDICATOR | INDICATOR |
| 16. | 2479U534S16 | [1] | INDICATOR | INDICATOR |
| 17. | 2479U534S17 | [1] | DIVIDER SOCKET | DIVIDER SOCKET |
