凯斯零件查询(LBX332R) - BIG RECTANGULAR BALER ''ROTOR CUTTER'' (3/03-12/08) (06.01A[02]) - CONTROL BOX - D480 Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
343 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
87326226
|
[1] |
ECU
|
ZED
(2 to 17, fig. 06.01B 01), Serial Range: -F480499
|
| 1. |
87362600
|
[1] |
ECU
|
ZED
(2 to 17, fig. 06.01B 02), Serial Range: -F500567 Superseded by part number: 87541260
|
| 1. |
87541260
|
[1] |
ECU
|
ZED
(2 to 17, fig. 06.01B 02), Start Serial: D568
|
| 1. |
87541260R
|
[1] |
REMAN ELECT CONTROL
|
ZED
FOR NA ONLY - LBX332P, LBX332R, LBX332S, LBX432R, LBX432S all Start Serial: D568 (3/03-)
|
| 1. |
87541260C
|
[1] |
CORE-ELECTRONIC CONT
|
ZED
FOR NA ONLY - Return Number
|
| 2. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
|
| 4. |
87349150
|
[1] |
PRINTED CIRCUIT BOAR
|
ZED
, Serial Range: -C567
|
| 4. |
87541259
|
[1] |
PRINTED CIRCUIT BOAR
|
ZED
, Start Serial: D568
|
| 5. |
87349912
|
[2] |
ELECTRIC CABLE
|
ZED
|
| 6. |
87349913
|
[1] |
CABLE
|
ZED
|
| 8. |
87339935
|
[2] |
PLUG
|
ZED
|
| 10. |
87349919
|
[1] |
CLAMP
|
ZED
, Serial Range: -C567
|
| 16. |
87339180
|
[1] |
DECAL
|
ZED
, Serial Range: -F480499 Superseded by part number: 87362602
|
| 16. |
87362602
|
[1] |
DECAL
|
ZED
, Serial Range: -F500567
|
| 16. |
87593607
|
[1] |
DECAL
|
ZED
, Start Serial: D568 Superseded by part number: 87362602
|
| 17. |
84460798
|
[1] |
CABLE
|
ZED
|
