神钢零件查询(K935) - EXCAVATOR SUPPLEMENT ASN LU00154 (1/76-12/03) (07-019) - HEATER, INST (FRESH AIR TYPE) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
452 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J6699F2 | [1] | HEATER, INST (FOR FREASH AIR TYPE) | |
| 1. | 24100P1066F1 | [1] | HEATER ASSY | HEATER ASSY |
| 2. | 2418P9899D1 | [1] | PLATE | KOB |
| 3. | 2418P9899D2 | [1] | PLATE | KOB |
| 4. | 2418Z844 | [1] | RIGID TUBE | KOB |
| 5. | 2416T11025 | [1] | BRACKET | BRACKET |
| 6. | 2444Z2157 | [1] | SOCKET | KOB |
| 7. | ZC45X38014 | [2] | CLIP | KOBCLAMP Single Line -- ID 38.1 x 70.05mm Long Superseded by part number: ZC46X38014 |
| 8. | 2416Z302D5 | [2] | SHEET | KOB |
| 9. | 2444Z2158 | [1] | SOCKET | KOB |
| 10. | 2444Z2576 | [1] | PLUG | PLUG |
| 11. | 2418T10455 | [2] | PIPE | KOB |
| 12. | R18T0026D17 | [1] | HOSE | KOBID 12 x OD 22 x 3300mm |
| 13. | R18T0026D13 | [1] | HOSE | KOBID 12 x OD 22 x 3800mm |
| 14. | 2444Z2155D3 | [2] | HOSE | KOB |
| 15. | 2444Z2156D4 | [1] | HOSE | KOB |
| 16. | 2420Z699 | [1] | GROMMET | KOB |
| 17. | 2432Z290 | [5] | CLIP | KOBWire Ties -- 185mm Long Superseded by part number: PY01P01043D3 |
| 18. | R16T0238D1 | [4] | CLIP | KOB |
| 19. | ZC15X02300 | [4] | CLIP | KOB |
| 20. | 2479Z913 | [1] | WIRE HARNESS | KOB |
| 21. | R44T0180 | [2] | COCK | KOB |
| 22. | ZC45X46014 | [2] | CLIP | KOBID 46mm Single Cable Superseded by part number: ZC46X46014 |
| 23. | ZM11C12025 | [2] | SCREW | KOBM12x1.75x25mm (Incls. Lockwasher) Superseded by part number: ZM12C12025 |
| 24. | ZM11C10025 | [5] | BOLT | KOBM10x1.50x25mm (Incls. Lockwasher) Superseded by part number: ZM12C10025 |
| 25. | ZM11C08020 | [2] | BOLT | KOBM08x1.25x20mm (Incls. Lockwasher) Superseded by part number: ZM12C08020 |
| 26. | ZM11C06016 | [2] | BOLT | KOB |
| 27. | ZN11C12010 | [2] | NUT | KOBM12x1.75mm Superseded by part number: ZN18C12010 |
| 28. | ZN11C08007 | [2] | NUT | KOBM08x1.25mm Superseded by part number: ZN16C08007 |
| 32. | 2427R558 | [1] | MAT, FLOOR | |
| 33. | 2427R559 | [1] | MAT, FLOOR | |
