神钢零件查询(K935) - EXCAVATOR SUPPLEMENT ASN LU00154 (1/76-12/03) (07-020) - COOLER ASSY, CAR P/N 24100J3944F2 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
352 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J3944F2 | [1] | COOLER ASSY, CAR | |
| 1. | 2452U172F1 | [1] | COMPRESSOR | |
| 1-1. | 2452UI72S1 | [1] | COMPRESSOR | |
| 1-2. | 2452U172S2 | [1] | CLUTCH | |
| 1-3. | 2452U172S3 | [1] | CAP SCREW | |
| 1-4. | 2452U172S4 | [1] | WASHER | |
| 1-5. | 2452U172S5 | [3] | CAPSCREW | |
| 2. | 2452U170 | [1] | CONDENSER | |
| 3. | 2452R5 | [1] | TANK, LIQUID | |
| 4. | 2452U171 | [1] | COOLING UNIT | |
| 6. | R06P0004D4 | [1] | V-BELT | |
| 8. | 2416P6241 | [1] | BRACKET | |
| 9. | 2416R134 | [1] | BRACKET | |
| 10. | 2444Z1949 | [1] | ADAPTER | |
| 11. | 2444Z1950 | [1] | ADAPTER | |
| 12. | 2416P4314 | [1] | BRACKET | |
| 13. | 2416P4315 | [1] | BRACKET | |
| 14. | 2452R8F1 | [1] | DUCT ASSY | |
| 15. | 2418T7951 | [1] | PLATE | |
| 17. | 2420R458D2 | [1] | HOSE | |
| 18. | 2420R456D7 | [1] | HOSE | |
| 19. | 2420Z841D1 | [1] | HOSE | |
| 21. | 2420Z786 | [2] | CAPSCREw | |
| 22. | 2444Z1955 | [1] | FITTING | |
| 23. | 2444Z1893 | [1] | FITTING | |
| 24. | 2444Z1954 | [1] | FITTING | |
| 25. | 2432Z322 | [6] | CLAMP | |
| 26. | 2432Z323 | [6] | CLAMP | |
| 27. | 2432Z186D6 | [10] | CLIP | |
| 28. | 2432Z187 | [10] | RING, CLIP | RING, CLIP |
| 29. | R16T0066D5 | [2] | SEAL | |
| 31. | R16T0443D2 | [2] | GROMMET | |
| 32. | 2444Z1956 | [1] | FITTING | |
| 33. | 2444Z1692 | [2] | FITTING | |
| 34. | 2444Z1895 | [4] | FITTING | |
| 35. | 2444Z1891 | [1] | FITTING | |
| 36. | 2444Z1953 | [1] | FITTING | |
| 37. | ZS11C10040 | [4] | CAPSCREW | |
| 36. | ZS11C10025 | [4] | CAP,Hex, M10 x 25mm, Cl 4.8 | KOBScrew -- M10x1.50x25mm Superseded by part number: ZS18C10025 |
| 39. | ZS12C10055 | [5] | SCREW,Hex, M10 x 55mm | KOBM10x1.50x55mm Superseded by part number: ZS18C10055 |
| 40. | ZS12C08040 | [4] | CAPSCREW | |
| 41. | ZS11C08030 | [4] | CAPSCREW | |
| 42. | ZS11C06045 | [4] | CAPSCREW | |
| 43. | ZS11C06030 | [4] | CAPSCREW | |
| 44. | ZS11C06016 | [2] | CAPSCREW | |
| 45. | ZS31C08016 | [2] | CAPSCREW,Phillips Drive, Pan HD, M8 x 16mm | KOBSCREW M08x1.25x16mm |
| 46. | ZN11C10008 | [4] | NUT | KOBM10x1.50mm Superseded by part number: ZN18C10008 |
| 47. | ZN11C08007 | [6] | NUT | KOBM08x1.25mm Superseded by part number: ZN16C08007 |
| 46. | ZN11C06005 | [14] | NUT | KOBNUT M06x1.0mm Superseded by part number: ZN18C06005 |
| 49. | ZW11X10000 | [13] | WASHER | KOBID 10 x OD 21 x Th 2.0mm Superseded by part number: ZW16X10000 |
| 50. | ZW11X08000 | [14] | WASHER | KOBID 09 x OD 17 x Th 1.6mm Superseded by part number: ZW16X08000 |
| 51. | ZW11X06000 | [12] | WASHER | KOBID 06.6 x OD 12.5 x Th 1.6mm Superseded by part number: 86588450 |
| 52. | ZW11X04000 | [4] | WASHER | |
| 53. | ZW22X10000 | [13] | LOCK WASHER | KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000 |
| 54. | ZW22X08000 | [10] | LOCK WASHER | KOBID 08 x OD 15.4 x Th 2.0mm Superseded by part number: 83990583 |
| 57. | ZS11C06020 | [4] | CAPSCREW M06x1.0x20mm | CAPSCREW M06x1.0x20mm |
| 56. | 2416N2334 | [1] | BRACKET | |
