纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (03-014[00]) - HYDRAULIC LINES, BOOM CYLINDER New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
474 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT42H00100F1 | [1] | Cylinder Boom | |
| 1. | YT42H00113F1 | [1] | PIPE | KOBHyd. Lines, Cylinder |
| 2. | YT42H01241P1 | [1] | TUBE | KOB |
| 3. | ZA23F22008 | [1] | HYD CONNECTOR | KOB |
| 4. | ZD12P01800 | [1] | O-RING | KOB |
| 5. | ZG91S02000 | [1] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB |
| 6. | ZG91V02000 | [1] | LUBE NIPPLE | KOB |
| 7. | YT42H00117F1 | [1] | PIPE | KOBHyd. Lines, Cylinder |
| 8. | YT42H01383P1 | [1] | TUBE | KOB |
| 9. | YT42H01448P1 | [2] | BAND | KOB |
| 10. | ZA33F22008 | [1] | ELBOW,M30 x 1.5 ORB x 1/2" NPT | KOB |
| 11. | YR43H01003P1 | [2] | CLAMP | KOB |
| 13. | ZS18C10035 | [2] | SCREW,Hex, M10 x 35mm | KOBCap |
| 14. | ZS18C10050 | [2] | SCREW,Hex, M10 x 50mm | KOBCap |
| 15. | ZW16H10000 | [2] | WASHER | KOB |
| 16. | ZW26X10000 | [2] | LOCK WASHER | KOB |
| 17. | ZE72X06000 | [1] | PLUG | KOB |
