神钢零件查询(K935) - EXCAVATOR SUPPLEMENT ASN LU00154 (1/76-12/03) (06-016) - INSTAL CRAWLER TRCAK P/N 24100P755F1 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
554 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100P755F1 | [1] | INSTAL,CRAWLER TRACK | |
| 1. | 24100N1802F1 | [2] | TRACK-LINK ASSY | TRACK-LINK ASSY |
| 1-1. | 2424J138D1 | [47] | TRACK LINK | KOB |
| 1-2. | 2424J138D2 | [47] | TRACK LINK | KOB |
| 1-3. | 2424J139D1 | [1] | LINK | KOB |
| 1-4. | 2424J139D2 | [1] | LINK | KOB |
| 1-5. | 2405P221 | [47] | BUSHING | KOB Superseded by part number: 2405P221C2 |
| 1-6. | 2419P891 | [47] | PIN | KOB |
| 1-7. | 2405P222 | [1] | BUSHING | KOB Superseded by part number: 2405P222C2 |
| 1-8. | 2419P892 | [1] | PIN | KOB |
| 1-9. | 2418T4682 | [2] | COLLAR | KOB |
| 1-10. | 2419T1884 | [1] | PIN,10mm OD | KOB |
| 2. | 2424N119 | [96] | SHOE, 910 | SHOE, 910 |
| 3. | 2420T3777 | [384] | BOLT | KOB |
| 4. | 2420T3778 | [384] | NUT | KOB |
