纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (03-017[00]) - HYDRAULIC LINES, ARM CYLINDER New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
523 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT42H00094F1 | [1] | Cylinder Arm | |
| 1. | YT42H00125F1 | [1] | PIPE | KOBHyd. Lines, Cylinder |
| 2. | YT42H01030D1 | [1] | HOSE | KOB |
| 3. | YT42H01030D3 | [1] | FLEXIBLE HOSE | KOB |
| 4. | ZH22Z04000 | [1] | HYD CONNECTOR | KOB |
| 5. | ZG91U02000 | [1] | LUBE NIPPLE | KOB |
| 6. | ZD12P01800 | [2] | O-RING | KOB |
| 7. | YT42H00096F1 | [1] | PIPE | KOBHyd. Lines, Cylinder |
| 8. | YT42H01370P1 | [1] | TUBE | KOB |
| 9. | YT42H01450P1 | [1] | BAND | KOB |
| 10. | YT42H01244P1 | [1] | BAND | KOB |
| 11. | YR43H01003P1 | [1] | CLAMP | KOB |
| 12. | ZA23F22008 | [1] | HYD CONNECTOR | KOB |
| 14. | ZS18C10035 | [2] | SCREW,Hex, M10 x 35mm | KOBCap |
| 15. | ZS18C10050 | [1] | SCREW,Hex, M10 x 50mm | KOBCap |
| 16. | ZW16H10000 | [1] | WASHER | KOB |
| 17. | ZW26X10000 | [2] | LOCK WASHER | KOB |
