纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (03-015[02]) - ARM CYLINDER INSTALLATION New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
414 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | NSS | [1] | NOT SERVICED SEPARATELY | CONTube Assy. |
| 3. | YT01V00031S003 | [1] | CYLINDER HEAD | KOB |
| 4. | EN01V00009S004 | [1] | BUSHING | KOB |
| 5. | 2438U716S6 | [1] | SNAP RING | KOB |
| 6. | LF01V00006S006 | [1] | RING | KOBBack Up |
| 7. | 2438U716S15 | [1] | RING | KOBU |
| 8. | YT01V00002S009 | [1] | RING | KOB |
| 9. | ZD12G09000 | [2] | O-RING,89.40mm ID x 95.60mm OD x 3.10mm | KOB |
| 10. | PH01V00018S008 | [1] | BACK-UP RING | KOB |
| 11. | ZD11G09500 | [1] | O-RING,94.40mm ID x 100.60mm OD x 3.10mm | KOB |
| 12. | YT01V00031S012 | [1] | HOLDER | KOB |
| 13. | YJ01V00002S007 | [1] | RING | KOBBack Up |
| 14. | LE01V00001S014 | [1] | BEARING | KOB |
| 15. | YT01V00031S015 | [1] | SEAL | KOBRing, Back Up |
| 16. | YT01V00031S016 | [1] | PISTON | KOB |
| 17. | 2438U1379S15 | [1] | SEAL RETAINER | KOBRing |
| 18. | PH01V00018S012 | [2] | RING | KOB |
| 19. | 2438U986S18 | [1] | SET SCREW | KOBSet |
| 20. | 2436U281S37 | [1] | BALL | KOB |
| 21. | YR01V00006S024 | [1] | BEARING | KOB |
| 22. | LF01V00002S024 | [1] | SEAL | KOB |
| 23. | YR01V00006S027 | [2] | STOP | KOB |
| 24. | YR01V00006S026 | [1] | RING | KOBRetaining |
| 25. | YT01V01002P2 | [4] | BUSHING | KOB |
| 26. | 2438U721S26 | [4] | SEAL | KOBRing, Wiper |
| . . | YT01V00031R100 | [1] | REPAIR KIT | KOBConsists Of Item: 6(1), 7(1), 8(1), 10(1), 11(1), 13(1), (9(2) |
| . . | YT01V00031R200 | [1] | REPAIR KIT | KOBConsists Of Item: 15(1), 17(1), 22(1), 18(2) |
| . . | YT01V00031R300 | [1] | REPAIR KIT | KOBConsists Of Item: 6(1), 7(1), 8(1), 10(1), 11(1), 13(1), 15(1), 17(1), 22(1), 9(1), 18(1) |
| . . | YT01V00031R400 | [1] | REPAIR KIT | KOBConsists Of Item: 1(1), 25(2), 26(2) |
| . . | YT01V00031R500 | [1] | REPAIR KIT | KOBConsists Of Item: 2(1), 25(2), 26(2) |
