| . . | 24100J2299F4 | [1] | ARM ASSY.3.25M | |
| 2. | 2406J114F1 | [2] | LINK | KOB |
| 2-2. | 2405T700 | [2] | BUSHING | BUSHING |
| 2-3. | 2405T701 | [1] | BUSHING | BUSHING |
| 3. | 2406J129F1 | [1] | LINK, BUCKET | LINK, BUCKET |
| 3-7. | 2405T698 | [2] | BUSHING | BUSHING |
| 3-8. | 2405T702 | [2] | BUSHING | KOB |
| 3-9. | 44Z1D10 | [2] | FITTING | KOBFITTINGS |
| 6. | 2419P2396 | [3] | PIN | KOB |
| 7. | 2419P2397 | [1] | PIN | KOB |
| 8. | 2419P2395 | [2] | PIN | PIN |
| 9. | 2418P4454 | [1] | TUBE | KOB |
| 10. | 2418T5558 | [1] | TUBE | TUBE |
| 12. | 2432T995 | [1] | CLAMP | KOB |
| 13. | R16P0035D3 | [16] | CLAMP | KOB |
| 14. | B16T0006 | [2] | PLATE | PLATE |
| 16. | R16P0036D17 | [5] | CLAMP | CLAMP |
| 17. | ZX58N16160 | [2] | FLEXIBLE HOSE | KOB1600mm Long (63 in) |
| 18. | 2420R349D250 | [2] | HOSE,2500.00 mm | KOB |
| 20. | 2420R349D340 | [1] | HOSE | KOB3400mm Long (133-55/64 in) Superseded by part number: HX21E04340DX |
| 21. | 2420R349D230 | [1] | HOSE ASSY. | KOB2300mm Long (90-1/2 in), Start Serial: LU.0086,0096- |
| . . | 2420R349D240 | [1] | HOSE,2400.00 mm | KOB, Start Serial: LU.0140- Superseded by part number: HX21E04240DX |
| 22. | R44P0034 | [2] | CONNECTOR | CONNECTOR |
| 23. | ZH32Z04000 | [2] | ELBOW | KOB90° -- (1/4" PT - 1/4" PT), (Incls. O-Ring ZD12P01100) |
| 24. | ZH22Z04000 | [6] | HYD CONNECTOR | KOB1/4"PTx1/4"PFx37mm Long |
| 25. | 2420T2747D7 | [6] | SHIM,112mm ID x 180mm OD x 1.2mm Thk | KOBID 112 x OD 180 x Th 1.2mm |
| 26. | 2420T2747D8 | [6] | SHIM,112mm ID x 180mm OD x 1.6mm Thk | KOBID 112 x OD 180 x Th 1.6mm |
| 27. | 2420T2747D9 | [6] | SHIM,112mm ID x 180mm OD x 2.3mm Thk | KOBID 112 x OD 180 x Th 2.3mm |
| 28. | 2420T2747D10 | [6] | SHIM,112mm ID x 180mm OD x 3.2mm Thk | KOBID 112 x OD 180 x Th 3.2mm |
| 29. | 2418T5224D1 | [2] | SHIM | KOB |
| 30. | 2418T5224D2 | [2] | SHIM | KOB |
| 31. | 2418T5224D3 | [2] | SHIM | KOB |
| 32. | 2418T5224D4 | [2] | SHIM | KOB |
| 33. | 2420T2747D2 | [2] | SHIM,102mm ID x 170mm OD x 1.2mm Thk | KOBID 102 x OD 170 x Th 1.2mm |
| 34. | 2420T2747D3 | [2] | SHIM,102mm ID x 170mm OD x 1.6mm Thk | KOBID 102 x OD 170 x Th 1.6mm |
| 35. | 2420T2747D4 | [2] | SHIM,102mm ID x 170mm OD x 2.3mm Thk | KOBID 102 x OD 170 x Th 2.3mm |
| 36. | 2420T2747D5 | [2] | SHIM,102mm ID x 170mm OD x 3.2mm Thk | KOBID 102 x OD 170 x Th 3.2mm |
| 38. | ZS18C12120 | [16] | SCREW,Hex, M12 x 120mm | KOBM12x1.75x120mm, Start Serial: LU.0086,0096- |
| . . | ZS18C12125 | [16] | CAP SCREW, Start Serial: LU.0143 | |
| 39. | ZS18C16080 | [4] | SCREW,Hex, M16 x 80mm | KOBM16x2.0x80mm |
| 40. | ZS18C12030 | [4] | SCREW,Hex, M12 x 30mm | KOBM12x1.75x30mm |
| 41. | ZS18C08012 | [7] | SCREW,Hex, M8 x 12mm | KOBM08x1.25x12mm |
| 42. | ZS23C14075 | [4] | CAPSCREW,Hex Socket Head, M14 x 75mm | KOBSCREW M14x2.0x75mm |
| . . | ZN18C12010 | [32] | NUT | KOBM12x1.75mm |
| 44. | ZS23C14035 | [4] | SCREW,Hex Socket Head, M14 x 35mm | KOBM14x2.0x35mm |
| 45. | ZW16X16000 | [4] | WASHER | KOBID 16 x OD 30 x Th 3.2mm |
| 46. | ZW16X12000 | [4] | WASHER | KOBID 12 x OD 24 x Th 2.3mm |
| 47. | ZW26X08000 | [7] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 48. | ZW26K14000 | [8] | LOCK WASHER | KOBID 14 x OD 21.8 x Th 3.5mm |
| 49. | ZD12P03800 | [2] | O-RING | KOBID 37.70 ± 0.37 x OD 44.7mm |
| 50. | 44Z1D10 | [13] | FITTING | KOB, Start Serial: LU.0086,0096- |
| . . | 44Z1D10 | [5] | FITTING | KOB, Start Serial: LU.0143 |
| 51. | ZN11C16013 | [4] | NUT | KOBM16x2.0mm |
| 52. | R16T0227D3 | [2] | SPACER | KOB |
| 53. | 2418T5364 | [2] | SPACER | KOB |
| 54. | ZG32B04000 | [2] | ELBOW | KOB90 |
| 55. | 2432P572D2 | [1] | CLAMP | |
| 57. | 2438U498F2 | [1] | CYLINDER, Serial Range: LU.0086,0096--LU.0142 | CYLINDER, Serial Range: LU.0086,0096--LU.0142 |
| . . | 2438U498F3 | [1] | CYLINDER, Start Serial: LU.0143\u2014 | CYLINDER, Start Serial: LU.0143— |
| 58. | 2411X650F1 | [1] | ARM, Serial Range: LU.0086,0096--LU.0139 | |
| . . | 2411X650D2F1 | [1] | ARM, Start Serial: LU.0140- | ARM, Start Serial: LU.0140- |
| 58-29. | 2405T702 | [4] | BUSHING | KOB, Serial Range: LU.0086,0096--LU.0140 |
| 56-30. | 2405T703 | [2] | BUSHING | KOB, Serial Range: LU.0086,0096--LU.0140 |
| 58-31. | 2418T5647D1 | [2] | SPACER | KOB, Serial Range: LU.0086,0096--LU.0140 |
| 58-34. | 2418T6152 | [1] | SPACER | KOB, Serial Range: LU.0086,0096--LU.0140 |
| 56-52. | 2411N1994 | [1] | REWORK,ARM, Start Serial: LU.0140 | |
| 59. | ZG91S02000 | [1] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight, Start Serial: LU.0143-- |
| 61. | 2411J3542F1 | [1] | ARM | ARM |
| 61-29. | 2405T702 | [8] | BUSHING | KOBLU.0141, Start Serial: - |
| 61-30. | 2405T703 | [2] | BUSHING | KOB |
| 61-31. | 2418T5647D1 | [2] | SPACER | KOB, Start Serial: LU.0141- |
| 61-34. | 2418T6152 | [1] | SPACER | KOB, Start Serial: LU.0141- |
