纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (03-023[02]) - ARM GROUP New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
347 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YT12B01176F1 | [1] | LINK | KOBBucket |
| 2. | YT12B01177P1 | [1] | LINK | KOBBucket |
| 3. | YR12B01079P1 | [2] | BUSHING | KOB |
| 4. | LE12B01055P1 | [2] | BUSHING | KOB |
| 5. | YT12B01024P1 | [1] | LINK | KOB Superseded by part number: YT12B01348P1 |
| 6. | YT12B01025P1 | [1] | LINK | KOB |
| 7. | YT12B01018P2 | [1] | PIN | KOB Superseded by part number: YT12B01345P1 |
| 8. | YT12B01019P1 | [1] | PIN | KOB Superseded by part number: YT12B01346P1 |
| 9. | HS18C12100G2 | [2] | SCREW | KOBCap |
| 10. | ZN18C12010 | [4] | NUT | KOB |
| 11. | 2445R138D19 | [4] | SEAL,50mm ID x 60mm OD x 4mm Thk | KOBDust |
| 12. | 2445R220D5 | [2] | SEAL,50mm ID x 65mm OD x 5mm Thk | KOBDust |
| 13. | ZG91S02000 | [6] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB |
| 14. | B16T0442D54 | [6] | SHIM,52mm ID x 80mm OD x 0.5mm Thk | KOB |
| 15. | B16T0442D41 | [6] | SHIM,80mm OD x 52mm ID x 0.9mm Thk | KOB |
| 16. | B16T0442D25 | [6] | SHIM,80mm OD x 52mm ID x 1.2mm Thk | KOB |
| 17. | YR12B01028P1 | [6] | SHIM | KOB2.0 |
