纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (03-024[00]) - ARM, LONG 2.13M New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
966 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT12B00210F1 | [1] | Long 2.13m | |
| 1. | YT12B00211F1 | [1] | ARM | KOBLong |
| 2. | YT12B00156F1 | [1] | ARM | KOBLong |
| 3. | YT12B00157P1 | [1] | ARM | KOBLong |
| 4. | YT12B01010P2 | [2] | BUSHING | KOB |
| 5. | LE12B01054P1 | [2] | BUSHING | KOB |
| 6. | YT12B01112P1 | [2] | BUSHING | KOB |
| 7. | YT12B00191P1 | [1] | ARM | KOBLong |
| 8. | YT12B01227P1 | [2] | BLOCK | KOBTapped |
| 9. | LC12B01560P1 | [2] | BLOCK | KOBTapped |
| 10. | YT12B00184P1 | [1] | ARM | KOB |
| 11. | YT12B01310P1 | [1] | PLATE | KOB |
| 12. | 2445R220D5 | [2] | SEAL,50mm ID x 65mm OD x 5mm Thk | KOBDust |
| 13. | 2445R138D19 | [2] | SEAL,50mm ID x 60mm OD x 4mm Thk | KOBDust |
| 14. | 2445R220D1 | [2] | SEAL,60mm ID x 75mm OD x 5mm Thk | KOBDust |
