纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (03-030[00]) - HYD LINES, ARM (NIBBLER & BREAKER) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
569 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT43H00077F1 | [1] | Arm (Nibbler & Breaker) | |
| 1. | YT43H01104P1 | [2] | TUBE | KOB |
| 2. | YT43H01013D9 | [2] | HOSE ASSY. | KOB |
| 3. | YT43H01144P1 | [2] | BRACKET | KOB |
| 4. | 24100P1006F1 | [2] | VALVE | KOBStop Superseded by part number: 24100P1006F2 |
| 5. | 2436P230 | [1] | VALVE BODY | KOB |
| 6. | 2436T304 | [1] | VALVE | KOB |
| 7. | 2418T8945D1 | [1] | SPACER | KOB |
| 8. | ZR16X04000 | [1] | RING | KOBRetaining |
| 9. | ZS23C06010 | [1] | SCREW,Hex Socket Head, M6 x 10mm | KOBCap |
| 10. | ZD11G04000 | [2] | O-RING,39.40mm ID x 45.60mm OD x 3.10mm | KOB |
| 11. | ZD12G04000 | [1] | O-RING,39.40mm ID x 45.60mm OD x 3.10mm | KOB |
| 12. | ZD75G04000 | [1] | BACK-UP RING | KOB |
| 13. | ZD12G03500 | [1] | O-RING,34.40mm ID x 40.60mm OD x 3.10mm | KOB |
| 14. | ZD85G03500 | [1] | RING | KOBBack-Up |
| 15. | ZA23F22012 | [2] | HYD CONNECTOR | KOB |
| 16. | ZD12P02400 | [2] | O-RING | KOB |
| 17. | YT43H01116P1 | [2] | CLAMP | KOB |
| 18. | ZS18C08025 | [8] | SCREW,Hex, M8 x 25mm | KOBCap |
| 19. | ZM73C10045 | [4] | BOLT,M10x45mm - Course Thread | KOBSems |
| 20. | YN43H01151P1 | [8] | WASHER | KOB |
| 21. | ZM73C12035 | [4] | BOLT,M12x35mm - Course Thread | KOBSems |
