神钢零件查询(K935) - EXCAVATOR SUPPLEMENT ASN LU00154 (1/76-12/03) (08-012) - LUB ASSY FOR LOADING Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
348 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100X471F1 | [1] | LUB ASSY | |
| 1. | 2420R349D360 | [1] | HOSE,3600.00 mm | KOB Superseded by part number: HX21E04360DX |
| 2. | 2420R349D180 | [2] | HOSE,6.35mm ID x 1800mm L | KOB1800mm Long (70-7/8 in) |
| 3. | 2420R349D14 | [1] | FLEXIBLE HOSE | KOB140mm Long (5-1/2 in) Superseded by part number: HX21E04100DX |
| 4. | 2420R349D11 | [2] | HOSE | HOSE |
| 5. | 2420R349D090 | [2] | HOSE,6.35mm ID x 900mm L | KOB900mm Long (35-7/16 in) |
| 6. | 2420R349D250 | [1] | HOSE,2500.00 mm | KOB |
| 7. | 2420R349D320 | [2] | HOSE ASSY. | KOB3200mm Long (126 in) |
| 8. | ZH32Z04000 | [5] | ELBOW | KOB90° -- (1/4" PT - 1/4" PT), (Incls. O-Ring ZD12P01100) |
| 9. | ZH22Z04000 | [19] | HYD CONNECTOR | KOB1/4"PTx1/4"PFx37mm Long |
| 10. | ZS11C08012 | [30] | SCREW,Hex, M8 x 12mm, Cl 4.8 | KOBM08x1.25x12mm Superseded by part number: ZS18C08012 |
| 12. | R16P0036D17 | [30] | CLAMP | CLAMP |
| 13. | 2420R349D190 | [1] | HOSE,6.35mm ID x 1900mm L | KOB1900mm Long (74-13/16 in) |
| 15. | 2444T727 | [7] | ELBOW | ELBOW |
| 19. | ZW22X08000 | [30] | LOCK WASHER | KOBID 08 x OD 15.4 x Th 2.0mm Superseded by part number: 83990583 |
| 22. | ZG32B04000 | [2] | ELBOW | KOB90° |
