纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (08-002[01]) - CYLINDER BLOCK New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
779 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VI8980894850 | [1] | CYLINDER BLOCK | KOBAsm. Superseded by part number: VI8980894851 |
| 2. | VI8942298530 | [5] | CUP | KOBSealing |
| 3. | VI8972096090 | [1] | SEAL | KOBCup |
| 4. | VI9096640010 | [1] | PLUG | KOBWater Drain |
| 5. | VI8941674701 | [10] | BOLT | KOBBrg. Cap |
| 6. | VI1096050190 | [1] | PLUG | KOBOil Gallery |
| 7. | VI9092045100 | [1] | PLUG | KOBOil Gallery |
| 8. | VI0410106200 | [4] | STUD | KOBOil Pan To Block |
| 9. | VI5096000130 | [6] | CUP | KOBSealing, Oil Gallery Superseded by part number: VI8970363351 |
| 10. | V18972621461 | [1] | Water Pump | |
| 11. | VI8980637940 | [1] | NEEDLE BEARING | KOB |
| 12. | VI9112290581 | [4] | DOWEL | KOBCyl. Block |
