纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (08-002[02]) - CYLINDER BLOCK New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
625 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VI8980894850 | [1] | CYLINDER BLOCK | KOBAsm. Superseded by part number: VI8980894851 |
| 2. | VI8942298530 | [5] | CUP | KOBSealing |
| 3. | VI9081506160 | [6] | PIN | KOBStraight |
| 4. | VI9081508160 | [2] | PIN | KOBFlywheel Hsg. |
| 5. | VI5096000130 | [6] | CUP | KOBSealing, Oil Gallery Superseded by part number: VI8970363351 |
| 6. | VI0280506120 | [4] | BOLT | KOBCover |
| 7. | VI8973296220 | [2] | NUT | KOBCover Fix |
| 8. | VI8980637570 | [8] | STUD | KOBPump Hole |
| 9. | VI8971189892 | [1] | COVER | KOBCyl. Block |
| 10. | VI8972621471 | [3] | STUD | KOBCover M6x16 L=25 |
| 10. | VI8972621481 | [1] | STUD | KOBCover M6x19 L=27 |
| 11. | VI8970394953 | [2] | PIN | KOBCont. Link |
| 12. | VI8942008190 | [2] | DOWEL | KOBCyl. Block |
| 13. | VI8970471421 | [1] | PLUG | KOBThrust |
| 14. | VI1096000122 | [1] | CAP | KOBSealing |
