纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (08-004[01]) - CAMSHAFT AND VALVE New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
717 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VI8971021231 | [4] | VALVE | KOBInl. |
| 2. | VI8970454103 | [4] | VALVE | KOBExh. |
| 3. | VI8971186561 | [1] | SHAFT | KOBRocker Arm |
| 4. | VI8980429440 | [1] | PLUG | KOBRocker Shaft End |
| 5. | VI0280506250 | [5] | BOLT | KOBRocker Arm Brkt., M6x25 |
| 5. | VI0280506500 | [5] | BOLT | KOBRocker Arm Brkt., M6x50 |
| 6. | VI8942395010 | [16] | SPLIT COLLAR | KOB |
| 7. | VI8970346291 | [8] | VALVE SPRING | KOB |
| 8. | VI8942510311 | [8] | BUSHING | KOBSeat; Spr. |
| 9. | VI8972125180 | [4] | ROCKER ARM | KOB |
| 10. | VI8972125200 | [4] | ROCKER ARM | KOB |
| 11. | VI8970104850 | [8] | SCREW | KOBAdj., Rocker Arm |
| 12. | VI0911115060 | [8] | NUT | KOBAdj., Screw, LK |
| 13. | VI8970695753 | [8] | PUSH ROD | KOB |
| 14. | VI8971243690 | [8] | TAPPET | KOBVlv., Start Serial: 200711-200804 Superseded by part number: 47543920 |
| 14. | VI8970346301 | [8] | TAPPET | KOBVlv., Start Serial: 200805 Superseded by part number: 47543920 |
| 15. | VI8973296220 | [6] | NUT | KOBRocker Shaft |
| 16. | VI8980488890 | [1] | BRACKET | KOBRocker Arm |
| 17. | VI8970706982 | [4] | SPRING | KOBRocker Shaft |
| 18. | VI9081505160 | [1] | PIN | KOBShaft Set |
| 19. | VI9111290830 | [1] | CUP | KOBSealing, Camshaft Superseded by part number: VI8970363351 |
| 20. | VI8972334290 | [1] | SEAL | KOBCup; Camshaft |
| 21. | VI9095714140 | [1] | GASKET | KOBCam End |
