凯斯零件查询(LBX332R) - BIG RECTANGULAR BALER ''ROTOR CUTTER'' (3/03-12/08) (06.99[04]) - CONNECTORS - FROM 84400775 TO 84806918 Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
327 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84400775
|
[1] |
MULTIPOLE CONNECTOR,Male, 23 Pole
|
ZED
|
| 2. |
84400776
|
[1] |
MULTIPOLE CONNECTOR,Male, 31 Pole
|
ZED
|
| 3. |
84400777
|
[1] |
LOCKING TAB,Wedge Lock
|
ZED
|
| 4. |
84400780
|
[1] |
MULTIPOLE CONNECTOR,Female, 23 Pole
|
ZED
|
| 5. |
84439475
|
[1] |
WIRE CONNECTOR
|
ZED
|
| 6. |
84439476
|
[1] |
WIRE CONNECTOR,Female
|
ZED
|
| 7. |
84441696
|
[1] |
WIRE CONNECTOR
|
ZED
1 - 2 MM²
|
| 8. |
84441874
|
[1] |
WIRE CONNECTOR
|
ZED
|
| 9. |
84449647
|
[1] |
MULTIPOLE CONNECTOR,Female, 8 Pole
|
ZED
|
| 10. |
84457868
|
[1] |
ELEC CONNECTOR
|
ZED
|
| 11. |
84457870
|
[1] |
PLUG
|
ZED
|
| 12. |
84457871
|
[1] |
SEAL PROTECTION
|
ZED
|
| 13. |
84457872
|
[1] |
TERMINAL CONNECTOR
|
ZED
Superseded by part number: 221381A1
|
| 14. |
84607213
|
[1] |
CONTACT HOUSING
|
ZED
|
| 15. |
84607242
|
[1] |
SEAL
|
ZED
|
| 16. |
84607243
|
[1] |
ELEC CONNECTOR,Female, 2 Cavities
|
ZED
Superseded by part number: 291718A1
|
| 17. |
84607244
|
[1] |
ELEC. TERMINAL PIN,Female, 0.5 - 1 mm2
|
ZED
Superseded by part number: 87679926
|
| 18. |
84607372
|
[1] |
CONTACT HOUSING,Female, 6 Pole
|
ZED
Superseded by part number: 87699698
|
| 19. |
84607373
|
[1] |
STOP DEVICE
|
ZED
|
| 20. |
84607374
|
[1] |
WIRE CONNECTOR
|
ZED
|
| 21. |
84607379
|
[1] |
MULTIPOLE CONNECTOR,Female, 10 Pole
|
ZED
|
| 22. |
84806090
|
[1] |
WIRE CONNECTOR
|
ZED
|
| 23. |
84806091
|
[1] |
WIRE CONNECTOR,Female, 3 Pin
|
ZED
|
| 24. |
84806208
|
[1] |
WIRE CONNECTOR
|
ZED
|
| 25. |
84806311
|
[1] |
WIRE CONNECTOR,Female, 8 Pin , 14 - 20 SAE
|
ZED
|
| 26. |
84806312
|
[1] |
LOCKING TAB,Wedge Lock
|
ZED
|
| 27. |
84806457
|
[1] |
CONNECTOR, ELEC
|
ZED
CONNECTOR Superseded by part number: 87679438
|
| 28. |
84806458
|
[1] |
COLLAR
|
ZED
|
| 29. |
84806460
|
[1] |
CABLE TERMINAL
|
ZED
2 - 3 MM²
|
| 30. |
84806654
|
[1] |
ELEC CONNECTOR,Female, 1 Pin
|
ZED
|
| 31. |
84806656
|
[1] |
CABLE TERMINAL
|
ZED
|
| 32. |
84806918
|
[1] |
WIRE CONNECTOR,Male, 8 Pin
|
ZED
Superseded by part number: 87708139
|
