神钢零件查询(MD140BLC) - EXCAVATOR BTW YP1001 - YP1281 (1/80-12/06) (01-002) - COUNTER WEIGHT ASSY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
862 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100P1705F7 | [1] | COUNTER-WEIGHT ASSV | |
| 2. | 2420Z933D3 | [4] | SCREW | KOB |
| 3. | R16T0152D4 | [4] | WASHER | KOBFlat -- ID 24 x OD 44 x Th 4.5mm |
| 4. | 2418T12306D2 | [2] | SHIM | KOB0.6 |
| 5. | 2418T12306D3 | [2] | SHIM | KOB0.4 |
| 6. | 2418T12306D6 | [2] | SHIM | KOB1.6 |
| 12. | 24100P1704F2 | [1] | COUNTER-WEIGHT ASSY | |
| 12-2. | 2479T1243 | [1] | INSULATION, SOUND | |
| 12-3. | 2422J2498 | [1] | COUNTER-WEIGHT | |
