纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (08-009[00]) - INLET MANIFOLD New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
716 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VI0280506200 | [4] | BOLT | KOBChamber |
| 2. | VI0280506600 | [3] | BOLT | KOBChamber |
| 3. | VI0280506800 | [1] | BOLT | KOBChamber |
| 4. | VI0362204100 | [4] | SCREW | KOB |
| 5. | VI8973149170 | [1] | PIPE | KOBAir |
| 6. | VI8941211130 | [1] | CLIP | KOBHose Superseded by part number: 8942420340 |
| 7. | VI5097003001 | [1] | HOSE CLIP | KOB |
| 8. | VI8980930310 | [1] | FLEXIBLE HOSE | KOBRubber Pcv |
| 9. | VI0410106160 | [1] | STUD | KOBDuct, Air Inlet |
| 10. | VI8970946411 | [1] | STUD | KOBDuct, Air Inlet |
| 11. | VI8973296220 | [2] | NUT | KOBDuct, Air Inlet |
| 12. | VI8972177780 | [1] | SENSOR | KOBBoost |
| 13. | VI8944280070 | [2] | BOLT | KOBSensor |
| 14. | VI8980751530 | [1] | CHAMBER | KOBInt. |
| 15. | VI0410106200 | [2] | STUD | KOBChamber |
| 16. | VI0911801060 | [2] | NUT | KOBChamber |
| 17. | VI8980305980 | [1] | GASKET | KOBChamber |
| 18. | VI5096000130 | [1] | CUP | KOBSealing Superseded by part number: VI8970363351 |
| 19. | VI8980457380 | [1] | VALVE | KOBPcv |
