纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (08-011[00]) - CRANKSHAFT, PISTON AND FLYWHEEL New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
485 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VI8980638280 | [1] | CRANKSHAFT | KOB |
| 2. | VI8980890840 | [1] | REPAIR KIT | KOBCrankshaft, Standard |
| 3. | VI8980306272 | [1] | ENGINE FLYWHEEL | KOB |
| 4. | VI8980891100 | [1] | CRANKSHAFT PULLEY | KOB |
| 5. | VI8973286120 | [1] | GEAR | KOBCr./Shf. |
| 6. | VI8980930180 | [1] | RING GEAR | KOB |
| 7. | VI8970232680 | [6] | WASHER | KOBFlywheel |
| 8. | VI8941333281 | [6] | BOLT | KOBFlywheel |
| 9. | VI8980637830 | [2] | WASHER | KOBThrust, Cr./Shf. |
| 10. | VI8943860790 | [1] | BOLT | KOBCr./Shf. Pulley |
| 11. | VI8942016410 | [1] | KEY | KOBWoodruff, Cr./Shf. |
| 12. | VI8941347920 | [1] | WASHER | KOBCr./Shf. Pulley |
| 13. | VI8980681581 | [4] | PISTON | KOB |
| 14. | VI8980681571 | [4] | PISTON ASSY | KOBO/S=0.25 |
| 15. | VI8980952150 | [4] | SET OF RINGS | KOBPiston, Standard |
| 16. | VI8980952160 | [4] | SET OF PISTON RINGS +0.6 | KOBO/S=0.25 Superseded by part number: 47543932 |
| 17. | VI8980957130 | [4] | SET OF CONN ROD BRGS (STD) | KOBMetal |
| 18. | VI5122110170 | [4] | PISTON PIN | KOB |
| 19. | VI8980757760 | [4] | CONNECTING ROD | KOBAsm. Superseded by part number: VI8980757761 |
| 20. | VI8980638260 | [4] | BUSHING | KOBConn. Rod |
| 21. | VI8980485360 | [8] | BOLT | KOBConn. Rod |
| 22. | VI8943777850 | [8] | NUT | KOBConn. Rod |
| 23. | VI8943699050 | [8] | SNAP RING | KOBPiston Pin |
