纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (08-012[00]) - EMISSION PIPNG New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
498 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VI8980305971 | [1] | VALVE | KOBEgr. |
| 2. | VI8980305360 | [1] | GASKET | KOBEgr. Vlv. |
| 3. | VI0911801080 | [4] | NUT | KOBEgr. Vlv. |
| 4. | VI5093000681 | [4] | STUD | KOBEgr. Vlv. |
| 5. | VI8973679180 | [2] | GASKET | KOBEgr. Pipe |
| 6. | VI8976018360 | [1] | GASKET | KOBEgr. Pipe |
| 7. | VI8980305330 | [2] | GASKET | KOBEgr. Pipe |
| 8. | VI8980116961 | [1] | BOLT | KOBPipe |
| 9. | VI8973296310 | [1] | CABLE CLIP | KOBHarness |
| 10. | VI0280506100 | [1] | BOLT | KOBBrkt. |
| 11. | VI0280508200 | [2] | BOLT | KOBBrkt. |
| 12. | VI0280508350 | [1] | BOLT | KOBBrkt. |
| 13. | VI0280508400 | [1] | BOLT | KOBBrkt. |
| 15. | VI8971616070 | [2] | NUT | KOBEgr. Pipe |
| 16. | VI8973780760 | [3] | BOLT | KOBEgr. Cooler |
| 17. | VI8980654810 | [3] | BOLT | KOBEgr. Cooler |
| 18. | VI8980305260 | [1] | BRACKET | KOBEgr. Cooler |
| 19. | VI8980958070 | [1] | COOLER | KOBEgr. Superseded by part number: VI8980958071 |
| 20. | VI8980958080 | [1] | PIPE | KOBEgr. |
| 21. | VI8980305310 | [1] | PIPE | KOBEgr. |
| 22. | VI8980960780 | [1] | ADJUSTING PLATE | KOBPipe, Egr. Superseded by part number: VI8980960781 |
| 23. | VI8980727120 | [1] | PLUG | KOBEgr. Cooler |
| 24. | VI9095714100 | [1] | SEAL | KOBPlug |
