凯斯零件查询(LBX332R) - BIG RECTANGULAR BALER ''ROTOR CUTTER'' (3/03-12/08) (07.07[01]) - HYDRAULICS KNIVES CROPCUTTER Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
244 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84819676
|
[2] |
PROTECTION CAP
|
ZED
Red
|
| 2. |
84819675
|
[2] |
PUSH-PULL COUPLING
|
ZED
Male
|
| 3. |
89511034
|
[2] |
SEAL
|
ZED
Superseded by part number: 722441
|
| 4. |
80434097
|
[1] |
BRACKET
|
ZED
Superseded by part number: 434097
|
| 5. |
84078071
|
[2] |
FLEXIBLE HOSE,6.35mm ID x 2500mm L, SAE 100R1
|
ZED
|
| 6. |
80753213
|
[3] |
CLAMP
|
ZED
Superseded by part number: 753213
|
| 7. |
84041508
|
[2] |
HYD CONNECTOR
|
ZED
|
| 8. |
80335135
|
[1] |
NUT
|
ZED
M8 Superseded by part number: 335135
|
| 9. |
80335136
|
[1] |
FERRULE
|
ZED
8 MM Superseded by part number: 335136
|
| 10. |
80371540
|
[1] |
RIGID TUBE
|
ZED
D= 8 MM, L= 2 M Superseded by part number: 371540
|
| 11. |
84064562
|
[1] |
HYD CONNECTOR
|
ZED
|
| 12. |
80335172
|
[1] |
HYD CONNECTOR
|
ZED
Superseded by part number: 335172
|
| 13. |
80379430
|
[1] |
3 WAY CONNECTION
|
ZED
Superseded by part number: 379430
|
| 14. |
85006175
|
[1] |
HYDRAULIC VALVE
|
ZED
, Serial Range: -C479
|
| 15. |
80386215
|
[6] |
HYD CONNECTOR
|
ZED
Superseded by part number: 386215
|
| 16. |
84043913
|
[2] |
COVER PLATE
|
ZED
|
| 17. |
120104
|
[2] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 18. |
80322358
|
[2] |
LOCK WASHER
|
ZED
8 MM Superseded by part number: 322358
|
| 19. |
89706690
|
[2] |
NUT,M8, Cl 8
|
ZED
Superseded by part number: 43362
|
| 20. |
84062569
|
[1] |
DRAINCOCK/TAP SUPPLY,M14 x 1.5 x M14 x 1.5
|
ZED
|
| 21. |
84045787
|
[1] |
BRACKET
|
ZED
|
| 22. |
80418283
|
[1] |
ELBOW
|
ZED
Superseded by part number: 418283
|
| 23. |
80350657
|
[1] |
RESTRICTOR VALVE
|
ZED
Superseded by part number: 350657
|
| 24. |
386215
|
[2] |
HYD CONNECTOR
|
ZED
, Serial Range: -C479
|
| 24. |
325172
|
[2] |
HYD TUBE
|
ZED
, Start Serial: D480
|
| 26. |
371540
|
[1] |
HYD TUBE,2000 mm Length
|
ZED
D= 8 MM, L= 2 M, Serial Range: -C479
|
| 26. |
87330800
|
[1] |
HYD TUBE
|
ZED
(8, 9) D= 8 MM, L= 1091 MM, Start Serial: D480
|
| 27. |
87331231
|
[1] |
HYD TUBE
|
ZED
(8, 9) D= 8 MM, L= 969 MM, Start Serial: D480
|
