纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (08-015[00]) - GENERATOR New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
852 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | VI8971822892 | [1] | GENERATOR | KOBAsm. |
| 1. | VI8971846390 | [1] | COVER | KOBAsm., RR, Gen. |
| 2. | VI8971846250 | [1] | ROTOR | KOBGen. |
| 3. | VI8971447400 | [1] | BEARING | KOBRotor, Gen. |
| 4. | VI8971447410 | [1] | BEARING | KOBRotor, Gen. |
| 5. | VI8971846280 | [1] | VOLTAGE REGULATOR | KOBAsm., Gen |
| 6. | VI8971846290 | [1] | ALTERNATOR | KOBRectifier; Gen |
| 7. | VI8971846240 | [1] | COVER | KOBAsm., Frt., Gen. |
| 8. | VI8971453270 | [1] | NUT | KOBPulley, Gen. |
| 9. | VI8971846330 | [1] | PULLEY | KOBGen. |
| 10. | VI8971453280 | [1] | BOLT | KOBThrough, Gen. |
| 11. | VI8971846270 | [1] | ALTERNATOR | KOBStator; Gen. |
| 12. | VI8971455160 | [1] | NUT | KOBRectifier, Gen. |
| 13. | VI8971447380 | [2] | BRUSH | KOBGen. |
| 14. | VI8971447270 | [1] | SCREW | KOBFrt. Cover |
