纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (08-013[02]) - ENGINE ELECTRICAL CONTROL PARTS New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
297 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VI8980723151 | [1] | STARTER MOTOR | KOBAsm., See Figure 08-015-00 |
| 2. | VI0281512350 | [2] | BOLT | KOBStarter |
| 3. | VI0911115080 | [1] | NUT | KOBStarter |
| 4. | VI8971256001 | [1] | SWITCH | KOBOver Heat Warning |
| 5. | VI8980305740 | [1] | CONTROLLER | KOBEgr. |
| 6. | VI0915108080 | [1] | WASHER | KOBLK, Starter |
| 7. | VI9829322110 | [1] | ELECTRIC CABLE | KOBStarter Earth |
| 8. | VI1825530391 | [1] | RELAY | KOBSafety, Starter |
| 9. | VI8980305730 | [1] | TIMER | KOBGlow Plug |
| 10. | VI8970633010 | [1] | SENSOR | KOBThermo, Qos |
| 11. | VI5825500300 | [1] | RELAY | KOB |
