| 1. |
87531843
|
[1] |
WINDGUARD
|
ZED
|
| 1. |
87531846
|
[1] |
WINDGUARD
|
ZED
|
| 2. |
87377532
|
[1] |
SUPPORT
|
ZED
|
| 3. |
87377534
|
[1] |
SUPPORT
|
ZED
|
| 4. |
84801352
|
[1] |
ROLLER
|
ZED
|
| 5. |
86548974
|
[4] |
FLANGE,Bearing
|
ZED
Superseded by part number: 50591
|
| 6. |
325103
|
[2] |
BALL BEARING,25mm ID x 52mm OD x 15mm W
|
ZED
|
| 7. |
87377536
|
[4] |
TINE
|
ZED
|
| 8. |
87531831
|
[1] |
CHAIN,672mm L
|
ZED
, Serial Range: -C579
|
| 9. |
84818993
|
[1] |
CHAIN,1464mm L
|
ZED
|
| 10. |
84056308
|
[4] |
PLATE
|
ZED
|
| 11. |
120037
|
[1] |
CARRIAGE BOLT,Short Nk, M8 x 20mm, Cl 8.8, Full Thd
|
ZED
Superseded by part number: 86507486
|
| 12. |
322358
|
[1] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 13. |
9706690
|
[1] |
NUT,M8 x 1.25, Cl 8
|
NH
Superseded by part number: 43362
|
| 14. |
43140
|
[3] |
BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8
|
NH
, Serial Range: -C579
|
| 15. |
140017
|
[3] |
WASHER,M10 x 20mm OD x 2mm Thk
|
PA
Superseded by part number: 9820489
|
| 16. |
140045
|
[3] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 17. |
100016
|
[3] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 18. |
9706687
|
[2] |
BOLT,M12 x 1.75 x 30mm, Cl 8.8
|
NH
|
| 19. |
120044
|
[4] |
CARRIAGE BOLT,M12 x 1.75 x 30mm, Cl 8.8
|
NH
|
| 20. |
140046
|
[1] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 21. |
9706685
|
[1] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 22. |
84074952
|
[2] |
ARM
|
ZED
, Serial Range: -C579
|
| 22. |
84607735
|
[2] |
ARM
|
ZED
, Start Serial: D580
|
| 23. |
84041968
|
[2] |
LOCKING PLATE
|
ZED
|
| 24. |
338263
|
[2] |
CARRIAGE BOLT,Sht Sq Nk, M12 x 1.75 x 70mm, Cl 8.8
|
ZED
|
| 25. |
84818450
|
[2] |
CARRIAGE BOLT,M12 x 85mm, Cl 8.8
|
ZED
|
| 26. |
84074953
|
[2] |
SHAFT
|
ZED
|
| 27. |
9837788
|
[2] |
NUT,M24 x 3, Cl 8.8
|
ZED
|
| 28. |
437424
|
[2] |
COTTER PIN
|
GI
|
| 29. |
9838996
|
[2] |
COTTER PIN
|
NH
|
| 30. |
87323476
|
[1] |
SUPPORT
|
ZED
|
| 30. |
87323341
|
[1] |
SUPPORT
|
ZED
|
| 31. |
395087
|
[1] |
INSULATOR BLOCK
|
ZED
|
| 32. |
300662
|
[1] |
CARRIAGE BOLT,Sht Sq Nk, M12 x 1.75 x 80mm, Cl 8.8
|
NH
|
| 33. |
378245
|
[1] |
WASHER,13mm ID x 28.5mm OD x 2.7mm Thk
|
NH
|
| 34. |
100038
|
[1] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 35. |
120112
|
[1] |
BOLT,Hex, M10 x 1.5 x 40mm, Cl 8.8, Full Thd
|
NH
, Start Serial: D580
|
| 36. |
291186
|
[1] |
PROTECTION STRIP,9.9mm W
|
NH
L= 0.1 M, Start Serial: D580 Superseded by part number: 47560081, 47560080
|
| 37. |
86566990
|
[2] |
CABLE TIE,292mm OAL x 4.8mm W
|
ZED
CABLE STRAP, Start Serial: D600
|
