| 1. |
100020
|
[2] |
NUT,M16 x 2.0, Cl 8
|
NH
|
| 2. |
80140048
|
[2] |
WASHER
|
ZED
16 MM Superseded by part number: 140048
|
| 3. |
80140020
|
[2] |
WASHER
|
ZED
16 MM Superseded by part number: 80299
|
| 4. |
80310146
|
[4] |
FLANGE
|
ZED
, Serial Range: -C575 Superseded by part number: 310146
|
| 5. |
84039072
|
[2] |
DRIVEN SPROCKET
|
ZED
, Serial Range: -C575
|
| 5. |
87517108
|
[2] |
DRIVEN SPROCKET
|
ZED
, Start Serial: D576
|
| 6. |
80034439
|
[2] |
BALL BEARING
|
ZED
, Serial Range: -C575 Superseded by part number: 84188095
|
| 7. |
80120100
|
[6] |
BOLT,M6 x 1 x 20mm
|
ZED
Superseded by part number: 120100
|
| 8. |
80322357
|
[6] |
LOCK WASHER,Belleville, M6
|
ZED
Superseded by part number: 322357
|
| 9. |
15896221
|
[1] |
NUT,Hex, M6, 5.20mm High, Cl 10
|
ZED
Superseded by part number: 86500688
|
| 10. |
89509425
|
[2] |
RING
|
ZED
, Serial Range: -C575 Superseded by part number: 9509425
|
| 11. |
80378246
|
[1] |
WASHER
|
ZED
16 MM, Serial Range: -C575 Superseded by part number: 378246
|
| 12. |
80393062
|
[4] |
WASHER
|
ZED
, Serial Range: -C575 Superseded by part number: 393062
|
| 12. |
47407
|
[1] |
WASHER,16.7mm ID x 33.3mm OD x 0.75mm Thk
|
NH
, Start Serial: D576
|
| 13. |
80120047
|
[2] |
BOLT
|
ZED
M16 x 70 Superseded by part number: 120047
|
| 14. |
84038167
|
[2] |
HUB
|
ZED
|
| 15. |
84007380
|
[2] |
CHAIN,Roller, 72 Links x 19.05mm = 1371.6mm
|
ZED
(47)
|
| 16. |
80140045
|
[1] |
WASHER
|
ZED
Belleville, M10 Superseded by part number: 140045
|
| 17. |
100016
|
[1] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 18. |
80374894
|
[1] |
SCREW
|
ZED
M10 x 70 Superseded by part number: 811-10070
|
| 19. |
84807386
|
[1] |
DRIVEN SPROCKET
|
ZED
Z= 16 Superseded by part number: 84038168
|
| 20. |
80170012
|
[2] |
KEY
|
ZED
Superseded by part number: 170012
|
| 21. |
89801096
|
[2] |
WASHER
|
ZED
Superseded by part number: 9801096
|
| 22. |
80140046
|
[2] |
WASHER
|
ZED
12 MM Superseded by part number: 140046
|
| 23. |
80300388
|
[2] |
SCREW,M12 x 25mm
|
ZED
Cap, HH, CL 8.8, M12 x 1.75 x 25 Superseded by part number: 300388
|
| 24. |
84807384
|
[1] |
DRIVEN SPROCKET
|
ZED
Z= 13
|
| 25. |
80053048
|
[2] |
WASHER
|
ZED
Superseded by part number: 53048
|
| 26. |
84438926
|
[2] |
BALL BEARING,35mm ID x 72mm OD x 17mm W
|
NH
|
| 27. |
84038170
|
[2] |
DISC
|
ZED
|
| 28. |
84038166
|
[2] |
BUSHING,35.1mm ID x 42.4mm OD x 171mm L
|
ZED
|
| 29. |
80364908
|
[2] |
BEARING ASSY
|
ZED
Superseded by part number: 364908
|
| 30. |
80789992
|
[2] |
SPACER
|
ZED
Superseded by part number: 789992
|
| 31. |
80130012
|
[2] |
COTTER PIN
|
ZED
, Serial Range: -C491 Superseded by part number: 87400
|
| 32. |
80140119
|
[1] |
WASHER
|
ZED
Superseded by part number: 140119
|
| 33. |
80442293
|
[4] |
WASHER
|
ZED
, Serial Range: -C491 Superseded by part number: 442293
|
| 34. |
84038270
|
[2] |
DRIVEN SPROCKET
|
ZED
Z= 46, Serial Range: -C491
|
| 34. |
84801570
|
[2] |
DRIVEN SPROCKET
|
ZED
Z= 46, Start Serial: D492
|
| 35. |
80036403
|
[4] |
FLANGE
|
ZED
, Serial Range: -C491 Superseded by part number: 86620026
|
| 35. |
86620026
|
[4] |
FLANGED BEARING
|
NH
, Start Serial: D492
|
| 36. |
80121602
|
[2] |
BALL BEARING
|
ZED
, Serial Range: -C491 Superseded by part number: 121602
|
| 36. |
212607
|
[2] |
BALL BEARING,35mm ID x 72mm OD x 51.1mm Thk
|
ZED
, Serial Range: -F492535 Superseded by part number: 84814912, 84814912, NLS
|
| 36. |
84814912
|
[2] |
BALL BEARING,35 mm ID x 72 mm OD x 51.1 mm
|
ZED
, Start Serial: D536 Superseded by part number: 87605590
|
| 37. |
86512411
|
[1] |
SHAFT
|
ZED
, Serial Range: -C491
|
| 37. |
84801572
|
[1] |
SPINDLE
|
ZED
, Serial Range: -F492655
|
| 38. |
43138
|
[1] |
BOLT,Hex, M10 x 1.5 x 20mm, Cl 8.8
|
NH
|
| 40. |
80412085
|
[2] |
SCREW
|
ZED
M12 x 80, Serial Range: -C491 Superseded by part number: 412085
|
| 41. |
84071653
|
[2] |
BUSHING
|
ZED
, Serial Range: -C491
|
| 42. |
80394630
|
[2] |
WASHER
|
ZED
12 MM, Serial Range: -C491 Superseded by part number: 86625256
|
| 43. |
80100038
|
[2] |
NUT
|
ZED
M12, Serial Range: -C491 Superseded by part number: 100038
|
| 44. |
84038268
|
[1] |
SHAFT
|
ZED
, Serial Range: -C491
|
| 44. |
84801574
|
[1] |
AXLE
|
ZED
, Serial Range: -F492655
|
| 45. |
84817286
|
[1] |
BUSHING,35.7mm ID x 48.3mm OD x 22mm L
|
ZED
, Serial Range: -C491
|
| 46. |
80025808
|
[1] |
LINK CHAIN
|
ZED
Superseded by part number: 86595251
|
| 47. |
80165590
|
[2] |
CONNECTING LINK
|
ZED
Superseded by part number: 241-1316
|
| 48. |
89838305
|
[4] |
WASHER
|
ZED
Superseded by part number: 9838305
|
| 49. |
370004
|
[2] |
SNAP RING,M35 x 1.5mm Thk, External
|
NH
, Start Serial: D492 Superseded by part number: 11068376
|
| 50. |
354775
|
[4] |
KEY,10mm x 8mm x 40mm
|
ZED
, Serial Range: -F492655
|
| 51. |
399417
|
[2] |
LOCK PIN,M10 x 60, Slotted
|
COE
, Serial Range: -F492655 Superseded by part number: 84977011
|
| 52. |
47704
|
[1] |
WASHER,35.7mm ID x 50.8mm OD x 5mm Thk
|
NH
, Start Serial: D492
|
| 53. |
378247
|
[2] |
WASHER,21mm ID x 39mm OD x 3mm Thk
|
ZED
, Start Serial: D576
|
| 54. |
325594
|
[2] |
WASHER,M17 x 40mm OD x 5mm Thk
|
ZED
, Start Serial: D576
|
