| . . | 24100J13429F6 | [1] | REMOTE-CONTROL ASSY | |
| 1. | 2420R349D330 | [2] | HYDRAULIC HOSE,6.35 mm ID x 3300.00 mm | KOB Superseded by part number: HX21E04330DX |
| 2. | 2444P1171D5 | [1] | HYD CONNECTOR | KOB |
| 3. | 2436U2590F1 | [1] | SOLENOID VALVE | KOB |
| 4. | ZX42M12035 | [1] | FLEXIBLE HOSE | KOB |
| 5. | ZH22X12000 | [1] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P02400) |
| 6. | 2420R349D130 | [3] | FLEXIBLE HOSE | KOB1/4" PF, 1300mm Long (51-3/16 in) |
| 7. | ZE72X04000 | [3] | PLUG | KOB(PF 1/4) (Incls. O-Ring ZD12P01100) |
| 8. | 2436R914F1 | [1] | INLET MANIFOLD | KOB Superseded by part number: 2436R914F2 |
| 9. | ZH32X06000 | [3] | 90 ELBOW,Male, 30 Degree Fl, PF 3/8" x PF 3/8", O-Ring | KOBElbow, 90° -- (Incls. O-Ring ZD12P01400) Alternate O-Ring 237-6006 |
| 14. | ZS13C08016 | [4] | SCREW | KOBM08x1.25x16mm Superseded by part number: ZS18C08016 |
| 16. | ZW22X08000 | [10] | LOCK WASHER | KOBID 08 x OD 15.4 x Th 2.0mm Superseded by part number: 83990583 |
| 24. | 2444Z2447F3 | [2] | ELBOW UNION | KOBUnion Elbow (WITH FILTER) |
| 25. | 2420R349D035 | [3] | HOSE | KOB350mm Long (13-49/64 in) |
| 26. | ZH52X04000 | [2] | TEE,30 Degree Fl, Male, PF 1/4" x 1/4" x 1/4", O-Ring | KOB1/4" PF (Incls. O-Ring 237-6004) |
| 28. | 2425Z519 | [3] | BALL | KOB |
| 30. | 2445R373F1 | [1] | ACCUMULATOR | KOB |
| 33. | ZW22X10000 | [9] | LOCK WASHER | KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000 |
| 34. | 2444Z2335 | [2] | CONNECTION | KOB |
| 36. | 2420R349D040 | [4] | HOSE,6.35mm ID x 400mm L | KOB1/4" PF, 400mm Long (15-3/4 in) |
| 39. | 2444Z2432 | [2] | TEE | KOB1/4" PF x (2) 3/8" PF x 52mm Long (Incls. O-Ring ZD12P01400) |
| 42. | 2444R1119D090 | [2] | HOSE | KOB |
| 44. | 2420R537D130 | [1] | HOSE,9.60mm ID x 1300mm L | KOB Superseded by part number: HX21E06130DX |
| 45. | 2420R349D150 | [6] | HOSE,6.35mm ID x 1500mm L | KOBPF 1/4 |
| 46. | 2420R537D180 | [1] | HOSE,9.60mm ID x 1800mm L | KOB1800mm Long (70-7/8 in) |
| 47. | 2444R1119D080 | [3] | FLEXIBLE HOSE | HIT |
| 48. | 2444Z2337 | [5] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01100) |
| 49. | 2444Z2893F1 | [1] | ELBOW UNION | KOBUnion Elbow |
| 50. | 2436U1282D2108 | [1] | VALVE PRESSURE RELIE | KOB |
| 51. | 2444Z4037D275 | [1] | HOSE | |
| 52. | ZH32X04006 | [1] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 3/8", O-Ring | KOB90° -- 1/4"x3/8"PF (Incls. O-Ring 237-6006 Alternate ZD12P01400) |
| 53. | 2444Z3279 | [1] | 90 ELBOW | KOB90° -- 3/8"PF-3/8"PFx32mm Long (Incls. O-Ring ZD12P01400) |
| 55. | 2416P15570 | [1] | BRACKET | BRACKET |
| 56. | ZS18C12025 | [2] | SCREW,Hex, M12 x 25mm | KOBM12x1.75x25mm |
| 57. | ZW26X12000 | [2] | LOCK WASHER | KOBID 12 x OD 21 x Th 3.0mm |
| 58. | 2444T2544 | [2] | ELBOW | KOB90° -- 1/4" PF (Incls. O-Ring ZD12P01100) |
| 59. | ZH22X04000 | [30] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB1/4"PFx36mm Long (Incls. O-Ring ZD12P01100) |
| 61. | 2444Z2448F2 | [1] | CONNECTOR ASSY (WITH FILTER) | CONNECTOR ASSY (WITH FILTER) |
| 62. | ZH32X04000 | [13] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 90° -- PF 1/4, (Incls. O-Ring 237-6004) |
| 64. | 2444Z2336 | [6] | TEE | KOBTee -- 1/4"x3/8"x3/8"PF (Incls. O-Ring ZD12P01100) |
| 65. | 2420R349D155 | [2] | HOSE,6.35mm ID x 1150mm L | KOB |
| 66. | 2444Z2338 | [11] | 90 ELBOW | KOB90° -- (1/4" PFx3/8" PF), (Incls. O-Ring ZD12P01100) |
| 67. | 2436U1453F2 | [1] | SOLENOID VALVE | KOB Superseded by part number: 2436U1453F4 |
| 68. | 2418T22461D1 | [1] | PLATE | KOBPLATE |
| 69. | ZS13C10025 | [5] | CAPSCREW | KOBSCREW M10x1.50x25mm Superseded by part number: ZS18C10025 |
| 71. | 2420R349D190 | [2] | HOSE,6.35mm ID x 1900mm L | KOB1900mm Long (74-13/16 in) |
| 73. | 2420R537D045 | [1] | HOSE,9.60mm ID x 450mm L | KOB Superseded by part number: HX21E06045DX |
| 74. | 2410T323 | [1] | BLOCK | KOB |
| 75. | ZS13C08040 | [6] | SCREW | KOBM08x1.25x40mm Superseded by part number: ZS18C08040 |
| 76. | 2420R349D085 | [2] | HOSE,6.35mm ID x 850mm L | KOB850mm Long (33-29/64 in) |
| 77. | 2436U2606F1 | [2] | PILOT VALVE | KOB |
| 78. | ZS23C06030 | [8] | SCREW,Hex Socket Head, M6 x 30mm | KOBM06x1.0x30mm |
| 79. | ZW11K06000 | [8] | WASHER | KOBID 06 x OD 11.5 x Th 1.6mm |
| 80. | ZN13C14011 | [2] | NUT | KOBM14x2.0mm Superseded by part number: ZN18C14011 |
| 83. | 2406R256F1 | [1] | HANDLE | KOB |
| 84. | 2406R256F2 | [1] | HANDLE | KOB |
| 85. | 2414N4225 | [2] | BOOT | KOB |
| 88. | 2420R349D210 | [8] | FLEXIBLE HOSE | KOB2100mm Long (82-11/16 in) |
| 89. | 2420R349D170 | [2] | FLEXIBLE HOSE | KOB1700mm Long (66-59/64 in) Superseded by part number: HX21E04170DX |
| 90. | 2420R349D160 | [3] | HOSE,6.35mm ID x 1600mm L | KOB |
| 95. | 2420R537D160 | [1] | HOSE,9.60mm ID x 1600mm L | KOB |
| 98. | 2444Z2447F1 | [1] | ELBOW UNION | KOBUnion Elbow (WITH FILTER) |
| 99. | 2444Z2891 | [2] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01400) |
| 100. | ZH22X06000 | [5] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01400) |
| 101. | 2444Z3155 | [2] | 90 ELBOW,PF 3/8" Fem x PF 3/8" Male | KOB90° -- (PF 3/8) (Incls. O-Ring ZD12P01400) Alternate O-Ring 237-6006 Superseded by part number: YT42H01128P1 |
| 103. | 2444Z3785 | [2] | HYD CONNECTOR | KOB1/4" PT (Incls. O-Ring ZD12P01100) |
| 104. | 2444Z2526 | [1] | TEE | KOB |
| 108. | 2479U1378 | [3] | PRESSURE SWITCH | KOB Superseded by part number: 2479U2010 |
| 111. | 2444Z2516 | [1] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01100) |
| 112. | ZH52X06000 | [2] | TEE,30 Degree Fl, Male, PF 3/8" x 3/8" x 3/8", O-Ring | KOB3/8"PFx54mm Long (Incls. O-Ring ZD12P01400) |
| 116. | 2420R564 | [1] | GROMMET | KOB |
| 117. | 2420Z1188 | [3] | GROMMET | KOB |
| 118. | 2432Z290 | [20] | CLIP | KOBWire Ties -- 185mm Long Superseded by part number: PY01P01043D3 |
| 124. | 2420R349D050 | [4] | HOSE,500.00 mm | KOB500mm Long (19-11/16 in) |
| 125. | 2444R1119D025 | [1] | FLEXIBLE HOSE | KOB |
| 126. | 2420R349D065 | [2] | HOSE,650.00 mm | KOB650mm Long (25-1/2 in) Superseded by part number: HX21E04065DX |
| 131. | 2414Z199D025 | [7] | PROTECTIVE SLEEVE | KOBHose -- 250mm Long (9-27/32 in) |
| 132. | 2420T3483 | [2] | GROMMET | KOB |
| 134. | 2432Z290D6 | [15] | CLIP | KOBWire Ties -- 292mm Long Superseded by part number: PY01P01043D5 |
| 135. | 2444Z3322D3 | [1] | HYD CONNECTOR | KOB1/8"PF x 1/8"PT x 25mm Long (Incls. O-Ring) |
| 138. | 2420R349D025 | [1] | HOSE | KOBFLEXIBLE HOSE Superseded by part number: HX21E04025DX, 77254021 |
| 142. | 2444R1119D060 | [1] | FLEXIBLE HOSE | HITHOSE 600 mm long (23-5/8 in) |
| 143. | 2444Z2359 | [1] | TEE | KOB3/8" PT (Incls. O-Ring ZD12P01400) |
| 144. | 2444Z2525 | [4] | HYD CONNECTOR | KOB1/4"PFx35mm Long (Incls. O-Ring ZD12P01100) Superseded by part number: 72217408 |
| 147. | 2444R402D7 | [1] | HYD CONNECTOR | KOB |
| 149. | 2444Z2894 | [1] | 90 ELBOW | KOBElbow, 90° -- 1/4" PF (Incls. O-Ring ZD12P01100) |
| 153. | 2444Z2544 | [2] | TEE | KOB1/4"PTx60mm Long (No O-Ring supplied) |
| 154. | 2444Z2546F1 | [2] | HYD CONNECTOR | KOB(WITH FILTER) |
| 158. | 2420R349D110 | [2] | HOSE,1100.00 mm | KOB1100mm Long (43-19/64 in) Superseded by part number: HX21E04110DX |
| 160. | 2444T3202 | [2] | HYD CONNECTOR | KOB |
| 161. | ZH22X04006 | [2] | HYD CONNECTOR | KOB(Incls. O-Ring 237-6006) |
| 162. | 2444Z3903 | [1] | ELBOW | KOB |
| 163. | 2444Z3227 | [4] | ELBOW | KOB |
| 164. | 2444Z3228 | [4] | ELBOW | KOB |
| 167. | 2420R537D060 | [1] | HOSE ASSY.,9.60mm ID x 600mm L | KOB |
| 171. | 2432T2518 | [1] | LABEL | KOBLABEL Superseded by part number: YN20T01133P1 |
| 176. | 2444R963D7 | [1] | HOSE,6.35mm ID x 500mm L | KOB |
| 180. | 2444Z2457 | [2] | TEE | KOB |
| 182. | 2420R349D100 | [1] | HOSE | KOB1000mm Long (39-3/8 in) Superseded by part number: HX21E04100DX |
| 185. | 2444Z2452 | [1] | HYD CONNECTOR | KOB |
| 186. | 2436U1171D21 | [1] | CHECK VALVE | KOB |
| 187. | 2436U1171D31 | [1] | CHECK VALVE | KOB |
| 188. | 2420R349D120 | [1] | HOSE,6.35mm ID x 1200mm L | KOB |
| 191. | 2444Z2447F2 | [1] | 90 ELBOW | KOB(WITH FILTER) |
| 192. | 2444Z3703 | [2] | ELBOW | KOB |
| 193. | 2444Z3421 | [1] | TEE | KOB(2) 3/8"PFx1/4"PFx54mm Long (Incls. O-Ring ZD12P01400) |
| 194. | 2444Z3541 | [1] | CONNECTION | KOB1/4" PF x 36mm Long (Incls. O-Ring ZD12P01100) Superseded by part number: 2444Z3759 |
| 197. | 2444T2613 | [1] | HYD CONNECTOR | KOB |
| 198. | 2444Z2522F1 | [1] | TEE | KOB(WITH FILTER) |
| 199. | ZW22K06000 | [8] | LOCK WASHER | KOBID 06 x OD 10 x Th 1.5mm |
| 201. | 2432N568 | [1] | INSTALLER JIG | KOB, Start Serial: YPU00402 Superseded by part number: 2432N1751 |
| 202. | 2432N578 | [1] | PLATE | KOB, Start Serial: YPU00402 |
| 203. | 2432N696 | [1] | INSTALLER JIG | KOB, Start Serial: YPU00402 Superseded by part number: 2432N1750 |
| 204. | 2432N1084 | [1] | INSTALLER JIG | KOB, Start Serial: YPU00402 Superseded by part number: 2432N1752 |
| 205. | 2444T2505 | [1] | HYD CONNECTOR | KOB1/4" PF - 3/8" PF x 35mm Long (Incls. O-Ring ZD12P01400) |
| 207. | 2444R1111F4 | [1] | HYD CONNECTOR | KOB |
| 207-1. | 2417T537 | [1] | SPRING | KOB |
| 207-2. | 2425Z551 | [1] | BALL | BALL |
| 207-5. | 2444Z3787 | [1] | HYD CONNECTOR | KOB Superseded by part number: 2444Z2294 |
| 207-7. | 2444Z3774 | [1] | TEE | KOBTEE Superseded by part number: 2444Z2526 |
| 207-8. | 2444Z3820 | [1] | 90 ELBOW | KOB90° -- 1/4" PT (Incls. O-Ring ZD12P01100) |
| 208. | 2444Z3765 | [2] | ELBOW | KOB |
| 210. | 2444R1119D050 | [1] | HOSE | KOB500mm Long (19-11/16 in) |
| 211. | 2444R1119D150 | [1] | FLEXIBLE HOSE | KOB |
| 212. | 2444R1119D035 | [1] | FLEXIBLE HOSE | KOB350mm Long (13-49/64 in) |
| 213. | 2444Z3832 | [3] | TEE | HIT |
| 214. | 2444Z3943 | [1] | ELEC CONNECTOR | KOB3/8" PF - 3/8"PFx 35mm Long (Incls. O-Ring ZD12P01400) |
| 215. | 2444Z3762 | [1] | TEE | KOB |
| 216. | 2444Z3619 | [1] | HYD CONNECTOR | KOB |
| 221. | 2436U2642F2 | [1] | HYDRAULIC VALVE | KOB |
| 222. | 2436R906F1 | [1] | VALVE | KOB |
| 223. | 2444T2533 | [1] | TEE | KOB(Incls. O-Ring ZD12P01400) Superseded by part number: 87635046 |
| 224. | 2444T3309 | [2] | TEE | KOB(2) 3/8" PF x 1/4" PF x 60mm Long (Incls. O-Ring ZD12P01100) |
| 227. | ZS13C10030 | [4] | SCREW | KOBM10x1.50x30mm Superseded by part number: ZS18C10030 |
| 228. | 2420R349D090 | [2] | HOSE,6.35mm ID x 900mm L | KOB900mm Long (35-7/16 in) |
| 230. | 2420R349D200 | [1] | HOSE ASSY. | KOB2000mm Long (78-3/4 in) |
| 231. | 2444R1120D160 | [1] | HOSE | KOB1600mm Long (63 in) |
| 233. | 2420R537D230 | [2] | FLEXIBLE HOSE,9.60mm ID x 2300mm L | KOB2300mm Long (90-1/2 in) |
| 234. | 2420R537D280 | [2] | HOSE,9.60mm ID x 2800mm L | KOB |
| 235. | 2436U2642F1 | [1] | HYDRAULIC VALVE | KOB |
