神钢零件查询(MD140C) - EXCAVATOR BTW YPU0301 - YPU0500 (1/80-12/06) (06-004) - LIGHT ASSY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
750 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2456U81F2 | [1] | WORK LAMP | KOBASSY |
| 1. | 2456U81S1 | [1] | LENS | KOB |
| 2. | 2456U81S2 | [1] | RIM | KOB |
| 5. | 2456U81S5 | [1] | STAY | |
| 6. | 2456U81S6 | [1] | BULB | KOB24Volt/70Watts Superseded by part number: YW80S00001S005 |
| 9. | 2456U81S9 | [2] | BOLT | |
| 15. | 2456U81S15 | [4] | SCREW | KOBTAPPING SCREW |
| 17. | 2456U81S17 | [1] | BOLT | |
| 18. | 2456U81S18 | [1] | NUT | |
| 19. | 2456U81S19 | [1] | WASHER, SPRING | |
| . . | 2456U74F1 | [1] | LIGHT ASSY. | KOB Superseded by part number: 2456U74F3 |
| 1. | 2456R229S8 | [1] | NUT | KOB |
| 2. | ZW26X14000 | [1] | WASHER | KOBID 14 x OD 24.5 x Th 3.5mm |
| 3. | 2456U74S3 | [1] | SCREW | KOB |
| 4. | 2456U74S4 | [1] | GROMMET | KOB |
| 6. | 2456R229S11 | [1] | SEALED BEAM UNIT | KOB Superseded by part number: 77259638, 2456R229S11M |
| 7. | 2456U74S7 | [1] | CUSHION | KOB |
| 10. | 2456U74S10 | [1] | SHEET | KOB |
| 11. | 2456U74S11 | [1] | NAME-PLATE | |
| 12. | 2456U74S5 | [1] | NOT SERVICED | KOB |
| 13. | 2456U74S8 | [1] | RING | KOB Superseded by part number: 2456U74S13 |
| 14. | 2456U74S9 | [1] | RING | KOB Superseded by part number: 2456U74S14 |
