| . . | 24100J11952F2 | [1] | INSTAL, LOW, Serial Range: YPU00301-YPU00349 | |
| . . | 24100J11952F3 | [1] | INSTAL, LOW, Start Serial: YPU00350 | |
| 1. | 2422J3160 | [1] | FRAME, LOW, Serial Range: YPU00301-YPU00349 | |
| 5. | NSS | [2] | NOT SOLD SEPARAT | CONSPRING ASSY, TRACK |
| 7. | 2404N271 | [2] | SPROCKET,21 T, 324mm ID x 601mm OD | KOB |
| 9. | 24100J5144F4 | [1] | FLEXIBLE JOINT | KOB Superseded by part number: 24100U1524F1 |
| 10. | 2422T556 | [1] | PLATE | KOB90x50x Th 06mm |
| 11. | 2418T12274 | [1] | PACKING | KOB90x50x Th 05mm -- Rubber |
| 12. | 2414N4360D1 | [1] | COVER | KOB |
| 13. | 2414N4360D2 | [1] | COVER | KOB |
| 14. | ZS13C16045 | [66] | SCREW | KOBScrew -- M16x2.0x45mm |
| 15. | ZS13C16065 | [56] | SCREW | KOBM16x2.0x65mm |
| 16. | ZS13C16050 | [40] | SCREW | KOBM16x2.0x50mm |
| 17. | ZS13C12025 | [13] | SCREW | KOBM12x1.75x25mm Superseded by part number: ZS18C12025 |
| 18. | ZS13C10016 | [2] | SCREW | KOBM10x1.50x16mm Superseded by part number: ZS18C10016 |
| 19. | ZS13C16090 | [4] | CAPSCREW | KOBSCREW M16x2.0x90mm |
| 20. | ZS13C16110 | [1] | SCREW | KOBM16x2.0x110mm |
| 21. | ZW22X12000 | [10] | LOCK WASHER | KOBID 12 x OD 21.5 x Th 3.0mm Superseded by part number: ZW26X12000 |
| 22. | ZW22X10000 | [2] | LOCK WASHER | KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000 |
| 23. | ZW11X12000 | [13] | WASHER | KOBID 12 x OD 24 x Th 2.3mm Superseded by part number: ZW16X12000 |
| 24. | ZW13H16000 | [40] | WASHER | KOBID 17 x OD 32 x Th 4.5mm |
| 25. | ZN13C16013 | [5] | NUT | KOBM16x2.0mm |
| 26. | 2441U829F1 | [2] | HYDRAULIC MOTOR | KOB Superseded by part number: 2441U829F5 |
| 27. | NSS | [2] | NOT SOLD SEPARAT | CONIDLER ASSY |
| 28. | NSS | [14] | NOT SOLD SEPARAT | CONROLLER ASSY (LOWER) |
| 29. | 2425U251F1 | [1] | SLEWING RING | KOB(PURCHASED PRODUCT) Superseded by part number: 24100N7529F1 |
| 29-1. | NSS | [1] | NOT SOLD SEPARAT | CONRACE, OUTER |
| 29-2. | NSS | [1] | NOT SOLD SEPARAT | CONRACE, INNER |
| 29-3. | 2425T321 | [108] | BALL | KOBØ25.4mm (1 in) Steel |
| 29-4. | 2425U238S4 | [108] | RETAINER | |
| 29-5. | NSS | [1] | NOT SOLD SEPARAT | CONPLUG |
| 29-6. | 2425U238S6 | [1] | PIN | KOBPIN, TAPER |
| 29-7. | 2425U238S7 | [1] | SEAL | KOB Superseded by part number: YW40F00001S007 |
| 29-8. | 2425U238S8 | [1] | SEAL | KOB |
| 29-9. | ZG91S02000 | [2] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
| 30. | 24100N6310F1 | [1] | RING, SLEWING (IN-HOUSE PRODUCT) | |
| 30-1. | 2425N366F1 | [1] | RACE, OUTER | |
| 30-2. | 2401N443 | [1] | RACE | KOBRACE, INNER |
| 30-3. | 2425T321 | [108] | BALL | KOBØ25.4mm (1 in) Steel |
| 30-4. | 2425T322 | [108] | RETAINER | KOB |
| 30-5. | 2445P165D6 | [1] | SEAL | KOBSEAL Superseded by part number: YN40F01024D4 |
| 30-6. | 2445P165D5 | [1] | SEAL | KOB Superseded by part number: YN40F01024D4 |
| 30-7. | 2432T1265 | [1] | LABEL | KOB Superseded by part number: YN22T00191P1 |
| 30-8. | 4020Z64 | [2] | RIVET | KOBOD 5.0 x 6.0mm Long Superseded by part number: 2420P623D7 |
| 30-9. | ZG91S02000 | [2] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
| 31. | NSS | [4] | NOT SOLD SEPARAT | CONROLLER ASSY (UPPER) |
| 32. | 2422J3530 | [1] | FRAME, LOW, Start Serial: YPU00350 | |
| . . | 2445P114D7 | [1] | SEAL KIT | KOBKIT Superseded by part number: YN40F01024D4 |
