神钢零件查询(MD140C) - EXCAVATOR BTW YPU0301 - YPU0500 (1/80-12/06) (07-007) - INSTAL, CRAWLER TRACK Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
790 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J12256F1 | [1] | INSTAL, CRAWLER TRACK | |
| 1. | 24100J12245F3 | [2] | LINK ASSY | LINK ASSY |
| 1-1. | 2424J380D1 | [45] | TRACK LINK | KOB Superseded by part number: 2424J167D1, LP62D01001P1 |
| 1-2. | 2424J380D2 | [45] | TRACK LINK | KOB Superseded by part number: LP62D01002P1 |
| 1-3. | 2405P419 | [44] | BUSHING | KOB Superseded by part number: 2405P695 |
| 1-4. | 2419P3277 | [44] | PIN | KOB Superseded by part number: 2419P3696 |
| 1-5. | 2405P418 | [2] | BUSHING | KOB Superseded by part number: 2405P696 |
| 1-6. | 2419P3386 | [1] | PIN, MASTER | PIN, MASTER |
| 1-7. | 2445Z1499 | [88] | SEAL | KOB |
| 1-8. | 2445Z1500 | [4] | SEAL | KOB |
| 1-9. | 2424N226 | [1] | CONNECTING LINK | KOB |
| 1-10. | 2424N227 | [1] | CONNECTING LINK | KOB |
| 1-11. | 2419P3278 | [1] | PIN | KOB Superseded by part number: 2419P3693 |
| 1-12. | 2419P3279 | [1] | PIN | KOB |
| 2. | 2424N183 | [92] | SHOE | KOB |
| 8. | 2420Z2036 | [368] | BOLT | KOB Superseded by part number: YY60D01003P1 |
| 10. | 2420Z2037 | [368] | NUT | KOB |
| . . | 24100J12256F2 | [1] | INSTAL, CRAWLER TRACK | |
| 2. | 2424N184 | [92] | SHOE | KOB Superseded by part number: 2424N264 |
| . . | 24100J12256F3 | [1] | INSTAL, CRAWLER TRACK | |
| 4. | 2424N184D2 | [92] | SHOE | KOB Superseded by part number: 2424N240D2 |
| . . | 24100J12256F4 | [1] | INSTAL, CRAWLER TRACK | |
| 6. | 2424J113C1 | [92] | TRACK SHOE | KOB |
| 9. | 2420T7345 | [368] | SCREW | KOBSHOE Superseded by part number: YY60D01005P1 |
| . . | 24100J12244F5 | [1] | INSTAL, CRAWLER TRACK | |
| 7. | B24K0018C1 | [92] | SHOE | KOB |
