神钢零件查询(MD140C) - EXCAVATOR BTW YPU0301 - YPU0500 (1/80-12/06) (07-006) - HYDR LINES, LOW Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
233 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J11997F2 | [1] | HYDR LINES, LOW | |
| 5. | 2418T21966 | [1] | TUBE | KOB |
| 6. | 2418P22723D1 | [1] | TUBE | KOB |
| 7. | 2418P22723D2 | [1] | TUBE | KOB |
| 8. | 2418P22724D1 | [1] | RIGID TUBE | KOB |
| 9. | 2418P22724D2 | [1] | RIGID TUBE | KOB |
| 20. | ZA23F22012 | [4] | HYD CONNECTOR | KOB3/4"PF - M30x1.50 x 46mm Long |
| 21. | ZA23B22000 | [6] | HYD CONNECTOR | KOBM30x1.50x38mm Long |
| 22. | ZA23B10000 | [2] | HYD CONNECTOR | KOBM16x1.50x50mm Long |
| 23. | ZA23F22008 | [2] | HYD CONNECTOR | KOB1/2" PT - M30x1.50 x 43mm Long |
| 24. | ZA23F10004 | [3] | HYD CONNECTOR | KOB1/4" PF x M16x1.50 x 33mm Long |
| 25. | 2444Z2320 | [4] | ELEC CONNECTOR | KOB1"PF-M30x1.50x48mm Long |
| 27. | ZD12P02400 | [4] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
| 28. | ZD12P01800 | [3] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 29. | ZD12P02900 | [4] | O-RING | KOBID 28.70 ± 0.29 x OD 35mm |
| 30. | ZD12P01100 | [3] | O-RING | KOBID 10.8mm x OD 13.2mm |
| 31. | ZA53B10000 | [1] | TEE | KOB(3) M16x1.50x46mm Long (No O-Ring supplied) |
| 32. | 2444Z2549 | [1] | TEE | KOB(2) M30x1.50 x 1/2"PF x 76mm Long (No O-Ring supplied) |
| 38. | 2418P23261D1 | [1] | TUBE | KOB |
| 39. | 2418P23261D2 | [1] | RIGID TUBE | KOB |
| 40. | 2418P23262D1 | [1] | TUBE | KOB |
| 41. | 2418P23262D2 | [1] | RIGID TUBE | KOB |
| 42. | 2418P23263D1 | [1] | TUBE | KOB |
| 43. | 2418P23263D2 | [1] | RIGID TUBE | KOB |
| 44. | 2418P23264D1 | [1] | RIGID TUBE | KOB |
| 45. | 2418P23264D2 | [1] | RIGID TUBE | KOB |
| 46. | 2418P23257 | [1] | RIGID TUBE | KOB |
| 47. | 2418P23258 | [1] | RIGID TUBE | KOB Superseded by part number: 2418P26595 |
| 48. | 2418P23259 | [1] | RIGID TUBE | KOB |
| 49. | 2418P23260 | [1] | RIGID TUBE | KOB |
| 50. | 2432T4778 | [2] | CLAMP | KOB150x38x25mm with 2 Taped M10x1.50 Holes |
| 51. | 2432T4779 | [2] | CLAMP | KOB150x38x25mm |
| 52. | 2414T2890 | [2] | PROTECTOR | KOBID 10 x OD 14 x 35mm Long |
| 53. | ZS23C10040 | [4] | SCREW,Hex Socket Head, M10 x 40mm | KOBM10x1.50x40mm |
| 54. | ZW22K10000 | [4] | LOCK WASHER | KOBLock -- ID 10.2 x OD 15.7 x Th 2.5mm |
