纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (02-007[00]) - TRACK ROLLER ASSEMBLY New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
181 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT64D00005F1 | [1] | Track | |
| 1. | YT64D00004F1 | [10] | TRACK ROLLER | KOBLow |
| 2. | 2413N456 | [1] | ROLLER | KOB |
| 3. | YT64D01006P1 | [1] | SHAFT | KOB |
| 4. | 2405P478 | [2] | BUSHING | KOB |
| 5. | YT64D01005P1 | [2] | PIN | KOB |
| 6. | 2445R439F1 | [2] | SEAL,64mm ID x 85.2mm OD x 28mm Thk | KOBFloating, Incl. Ref 7 - 8 |
| 7. | 2445R439S1 | [2] | SEAL | KOB |
| 8. | 2445R439S2 | [2] | O-RING | KOB |
| 9. | ZD11G03500 | [2] | O-RING,34.40mm ID x 40.60mm OD x 3.10mm | KOB |
| 10. | YT64D01003P1 | [2] | RING | KOB |
| 11. | ZE82T04000 | [2] | PLUG | KOB |
| 12. | LE64D01004P1 | [40] | SCREW | KOBCap |
