纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (02-010[02]) - CYLINDER INSTALLATION New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
405 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | NSS | [1] | NOT SERVICED SEPARATELY | CONTube Assy. |
| 3. | LF01V00008S003 | [1] | PISTON | KOB |
| 4. | LF01V00008S004 | [1] | NUT | KOB |
| 5. | LF01V00008S005 | [1] | CYLINDER HEAD | KOB |
| 6. | LF01V00008S006 | [2] | RING | KOB |
| 7. | LF01V00008S007 | [1] | SEAL | KOB |
| 8. | YT01V00035S008 | [1] | BEARING | KOB |
| 9. | YT01V00035S009 | [1] | WEAR RING | KOBRetaining |
| 10. | YT01V00035S010 | [1] | SEAL | KOB |
| 11. | YT01V00035S011 | [1] | RING | KOBBack Up |
| 12. | YT01V00035S012 | [1] | SEAL | KOBRing |
| 13. | ZD12P11200 | [1] | O-RING | KOB |
| 14. | ZD85P12000 | [1] | BACK-UP RING | KOB |
| 15. | ZD11G13000 | [1] | O-RING,129.40mm ID x 135.60mm OD x 3.10mm | KOB |
| 16. | YT01V00035S016 | [2] | BEARING | KOB |
| 17. | YT01V00035S017 | [4] | SEAL | KOBRing |
| 18. | YT01V00035S018 | [2] | FITTING | KOBNipple, Grease |
| 19. | YT01V00035S019 | [1] | SEAL | KOBRing, Buffer |
| . . | LF01V00008R100 | [1] | PIPE | KOBRepair Kit, Consists Of Item: 1(1), 16(1) |
| . . | LF01V00008R200 | [1] | ROD | KOBRepair Kit, Consists Of Item: 2(1), 16(1) |
| . . | LF01V00008R300 | [1] | REPAIR KIT | KOBConsists Of Item: 7(1), 10(1), 11(1), 12(1), 13(1), 14(1), 15(1), 19(1), 6(2) |
