| 2. |
87741343
|
[1] |
STEEL PLATE
|
NH
Front
|
| 14. |
9807866
|
[1] |
SHAFT
|
NH
Center, 28T / 28T
|
| 15. |
86526406
|
[1] |
SHAFT
|
NH
LH, 23T / 28T
|
| 16. |
9807868
|
[1] |
SHAFT
|
NH
RH, 28T
|
| 18. |
9801475
|
[1] |
LINK CONROD
|
PA
Superseded by part number: 86641549
|
| 23. |
9822717
|
[1] |
ARM
|
PA
Superseded by part number: 89822717, 86641570
|
| 25. |
86620026
|
[2] |
FLANGED BEARING
|
NH
|
| 34. |
511265
|
[1] |
SPROCKET
|
NH
Idler, 15T, #60 Chain
|
| 35. |
9822718
|
[1] |
DRIVEN SPROCKET
|
PA
39T, Includes Ref. 80 Superseded by part number: 86641571
|
| 36. |
103244
|
[1] |
SPROCKET
|
NH
17T
|
| 38. |
848756
|
[1] |
CHAIN
|
NH
#R606 Riveted Type, 80 Total Pitches, 5/8" Pitch Includes: Ref. 74 & 75 Superseded by part number: 1791DX
|
| 39. |
9847046
|
[1] |
CHAIN
|
NH
#60H Riveted Type, 84 Total Pitches, 3/4" Pitch, Includes: Ref. 76 & 77 Superseded by part number: 1793DX
|
| 41. |
47067
|
[1] |
RETAINER COLLAR,34.92mm ID x 56.33mm OD x 17.46mm Thk
|
MKT
Superseded by part number: 47577188
|
| 43. |
47066
|
[1] |
BALL BEARING,35mm ID x 72mm OD x 19mm W
|
GI
|
| 46. |
9671424
|
[1] |
SNAP RING,#137, Ext
|
PA
|
| 49. |
88682
|
[3] |
CARRIAGE BOLT,Short Nk, 3/8"-16 x 1", Gr 5
|
NH
|
| 52. |
280466
|
[2] |
CARRIAGE BOLT,Short Sq Nk, 5/8" - 11 x 2 1/2", Gr 5
|
NH
|
| 57. |
46402
|
[3] |
SHEAR BOLT
|
NH
Superseded by part number: 46047
|
| 58. |
49637
|
[4/AR] |
WASHER,16.5mm ID x 30mm OD x 2.99mm Thk
|
NH
|
| 59. |
58630
|
[1] |
WASHER,.0299" Thk
|
NH
|
| 60. |
604937
|
[3] |
WASHER,16.7mm ID x 52.4mm OD
|
NH
|
| 62. |
130357
|
[1] |
WASHER,35.3mm ID x 60.3mm OD x 1.52 Thk
|
NH
|
| 63. |
87365
|
[4/AR] |
WASHER,0.66" ID x 1.31" OD x 0.1" Thk
|
NH
|
| 66. |
140045
|
[3] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 67. |
9800957
|
[3/AR] |
WASHER,35.81mm ID x 50.8mm OD x 1.52mm Thk
|
NH
|
| 68. |
36732
|
[1] |
WASHER
|
PA
Superseded by part number: 86640786
|
| 70. |
9628503
|
[3] |
NUT,3/8"-16, G5
|
NH
|
| 72. |
86629544
|
[4] |
NUT,5/16” – 18, GR B
|
NH
Superseded by part number: 280736
|
| 73. |
19670
|
[2] |
NUT,5/8"-11, GB
|
NH
Superseded by part number: 85700693
|
| 74. |
25194
|
[1] |
CONNECTING LINK
|
GI
Spring Clip Superseded by part number: 86537460
|
| 75. |
25805
|
[79] |
LINK CHAIN
|
GI
Regular Superseded by part number: 241-1115
|
| 76. |
785210
|
[1] |
LINK,19.05mm Pitch
|
GI
Spring Clip
|
| 77. |
187609
|
[83] |
CONNECTING LINK
|
NH
Regular
|
