凯斯零件查询(SB551) - SMALL SQUARE BALER (9/08-12/15) (68.180.05) - TWINE BOX MOUNTING Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
701 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
87044650
|
[1] |
LID
|
PA
Superseded by part number: 84134299
|
| 4. |
86641578
|
[1] |
BRACKET
|
NH
Twine Guide
|
| 5. |
86543545
|
[1] |
GUIDE
|
NH
|
| 9. |
87728762
|
[1] |
SUPPORT
|
PA
RH
|
| 10. |
87728763
|
[1] |
SUPPORT
|
PA
LH
|
| 17. |
28114
|
[1] |
U-BOLT
|
NH
|
| 20. |
88011
|
[1] |
BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 5
|
NH
|
| 23. |
86521552
|
[4] |
BOLT,Hex, 5/16" - 18 x 3/4", Gr 5
|
NH
|
| 25. |
280327
|
[4] |
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 5, Full Thd
|
NH
|
| 26. |
523291
|
[6] |
BOLT,Hex Serr Flg, 1/4" - 20 x 1/2"
|
WIN
|
| 29. |
322358
|
[8] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 30. |
48055
|
[2] |
WASHER
|
NH
Superseded by part number: 285072
|
| 36. |
86521605
|
[8] |
FLANGE NUT,5/16"-18, Cl 5
|
NH
|
| 40. |
9628503
|
[1] |
NUT,3/8"-16, G5
|
NH
|
| 44. |
87304
|
[2] |
NUT,#10-24
|
BEL
|
| 45. |
42576
|
[3] |
NUT
|
NH
|
