神钢零件查询(MD140C) - EXCAVATOR BTW YPU0301 - YPU0500 (1/80-12/06) (13-005) - VALVE ASSY, CONTROL (SWING) P/N 2436U1456F1~F4 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
613 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2436U1456F1 | [1] | X | KOBCONSISTS OF THE FOLLOWING PARTS |
| . . | 2436U1456F2 | [1] | HYDRAULIC VALVE | KOBCONSISTS OF THE FOLLOWING PARTS |
| . . | 2436U1456F3 | [1] | CONSISTS OF THE FOLLOWING PARTS | |
| . . | 2436U1456F4 | [1] | CONTROL VALVE | KOB |
| 10. | NSS | [1] | NOT SOLD SEPARAT | CONCOVER, VALVE F3 & F4 ONLY |
| 11. | 2436U1457S301 | [1] | SPOOL F3 & F4 ONLY | |
| 12. | 2436U1457S15 | [1] | SPRING F3 & F4 ONLY | |
| 20. | 2436U1457S22 | [2] | SPRING F4 ONLY | |
| 21. | 2436R727F6 | [2] | VALVE PRESSURE RELIE | KOBF2 & F4 ONLY |
| 22. | 2436R790F2 | [2] | VALVE ASSY F2 & F4 ONLY | VALVE ASSY F2 & F4 ONLY |
| 101. | NSS | [1] | NOT SOLD SEPARAT | CONCASING |
| 151. | 2436U1165S154 | [2] | PLUG | KOB |
| 152. | 2436U368S151 | [1] | PLUG | KOB |
| 153. | 2436U1219S153 | [1] | PLUG | KOB |
| 161. | ZD12G03500 | [2] | O-RING,34.40mm ID x 40.60mm OD x 3.10mm | KOBID 34.40 ± 0.33 x OD 40mm |
| 162. | 2436U1457S162 | [2] | O-RING,2mm Thk x 39.5mm ID, 90 Duro | KOB |
| 163. | ZD12P00700 | [2] | O-RING,1.6mm Thk x 6.8mm ID, 90 Duro | KOBO-Ring -- ID 06.80 ± 0.16 x OD 10mm |
| 164. | ZD12P01400 | [2] | O-RING | KOBID 13.80 ± 0.19 x OD 18mm |
| 165. | ZD12P01800 | [1] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 166. | ZD12P01100 | [1] | O-RING | KOBID 10.8mm x OD 13.2mm |
| 171. | 2436U1457S171 | [6] | SCREW | KOB |
| 201. | 2436U1431S201 | [1] | COVER | |
| 202. | NSS | [1] | NOT SOLD SEPARAT | CONCOVER F1 & F2 ONLY |
| 211. | 2483U172S19 | [1] | BALL | KOB |
| 231. | NSS | [1] | NOT SOLD SEPARAT | CONSEAT |
| 251. | 2436U585S651 | [1] | PLUG | KOB Superseded by part number: YT30V00009S153 |
| 254. | 2436U1457S254 | [8] | PLUG | KOB |
| 261. | ZD12P01000 | [1] | O-RING | KOBID 09.80 ± 0.17 x OD 13mm |
| 263. | ZD12P00500 | [8] | O-RING | KOB |
| 271. | ZS23C08025 | [2] | SCREW,Hex Socket Head, M8 x 25mm | KOBM08x1.25x25mm |
| 272. | ZS23C08040 | [2] | SCREW,Hex Socket Head, M8 x 40mm | KOBM08x1.25x40mm Superseded by part number: ZS28C08040 |
| 301. | 2436U1431S301 | [1] | SPOOL F1 & F2 ONLY | SPOOL F1 & F2 ONLY |
| 321. | 2436U1431S321 | [1] | SPRING F1 & F2 ONLY | |
| 331. | 2436U1431S331 | [2] | SEAT, SPRING | SEAT, SPRING |
| 332. | 2436U1431S332 | [1] | SCREW | KOBSPACER |
| 333. | 2436U1431S333 | [1] | STOPPER | |
| 511. | 2436U1431S511 | [3] | POPPET | |
| 512. | 2436U1431S512 | [2] | POPPET | |
| 521. | 2436U1457S521 | [3] | SPRING | KOB |
| 522. | 2436U1431S522 | [2] | SPRING | KOBF1 TO F3 ONLY |
| 551. | 2436U1485S552 | [5] | PLUG | KOB |
| 561. | ZD12P02200 | [5] | O-RING | KOBID 21.80 ± 0.24 x OD 26mm |
| 601. | 2436R727F3 | [2] | VALVE PRESSURE RELIE | KOBASSY F1 & F3 ONLY |
| 602. | 2436R790F3 | [2] | VALVE | KOBASSY F1 & F3 ONLY Superseded by part number: 2436R790F8 |
| 901. | 24100U1156S891 | [1] | NAME-PLATE | |
