神钢零件查询(MD140C) - EXCAVATOR BTW YPU0301 - YPU0500 (1/80-12/06) (13-007) - MOTOR ASSY (SWING) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
858 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2441U962F1 | [1] | MOTOR ASSY (SWING) CONSISTS OF THE FOLLOWING PARTS | |
| 1. | NSS | [1] | NOT SOLD SEPARAT | CONCYLINDER |
| 2. | 2441U754S2 | [1] | RING | KOBRACE, INNER |
| 3. | 2441U754S3 | [1] | OIL SEAL | KOB Superseded by part number: 2437U369S33 |
| 4. | 2441U754S4 | [1] | TRACK ROLLER | KOBBEARING |
| 5. | NSS | [1] | NOT SOLD SEPARAT | CONCASE |
| 6. | 2441U754S6 | [1] | PLATE | KOB |
| 7. | 2441U828S7 | [1] | PLATE, RETURN | |
| 8. | 2441U828S8 | [1] | SPRING, BACKING | |
| 9. | NSS | [9] | NOT SOLD SEPARAT | CONPISTON ASSY |
| 10. | 2441U754S10 | [1] | PLATE | KOB |
| 11. | 2441U754S11 | [1] | PLATE | KOB |
| 12. | NSS | [1] | NOT SOLD SEPARAT | CONPISTON |
| 13. | 2441U754S12 | [1] | O-RING | KOB |
| 14. | 2441U754S14 | [2] | RING | KOB |
| 15. | 2441U754S16 | [20] | SPRING | KOB |
| 16. | 2441U754S17 | [2] | PIN | KOB |
| 17. | NSS | [1] | NOT SOLD SEPARAT | CONCOVER |
| 18. | ZD12P01100 | [3] | O-RING | KOBID 10.8mm x OD 13.2mm |
| 19. | 2436U1309S41 | [3] | CAP | KOB |
| 20. | 2441U754S23 | [4] | BUSHING | KOB |
| 21. | 2441U754S24 | [4] | SPRING | KOB |
| 22. | 2441U754S25 | [4] | RING | KOB |
| 23. | 2441U754S26 | [1] | PLATE | KOB |
| 24. | 2441U754S27 | [1] | NEEDLE BEARING | KOBBEARING |
| 25. | 2441U754S28 | [1] | RING | KOB |
| 26. | ZS23C12130 | [1] | SCREW,Hex Socket Head, M12 x 130mm | KOBM12x1.75x130mm |
| 27. | ZD12P02600 | [4] | O-RING | KOBID 25.70 ± 0.26 x OD 32mm |
| 28. | 2441U962S39 | [2] | VALVE ASSY, RELIEF | |
| 29. | 2441U754S20 | [1] | PLUG | KOB Superseded by part number: 2441U829S33 |
| 30. | ZS23C14045 | [4] | SCREW,Hex Socket Head, M14 x 45mm | KOBM14x2.0x45mm Superseded by part number: ZS28C14045 |
| 31. | 2441U962S42 | [2] | VALVE ASSY, BY-PASS | |
| 32. | ZD85P02100 | [2] | RING | KOBBack-Up -- ID 21 x OD 25 x Th 1.25mm |
| 33. | ZD12P02100 | [2] | O-RING,2.4mm Thk x 20.8mm ID, 90 Duro | KOBO-Ring -- ID 20.80 ± 0.23 x OD 25mm |
| 34. | 2441U962S45 | [2] | CHECK VALVE | KOB |
| 35. | 2441U962S46 | [2] | SPRING | KOB |
| 36. | ZD85P02600 | [2] | BACK-UP RING | KOBID 26 x OD 32 x Th 1.25mm |
| 37. | 2441U962S48 | [2] | PLUG | KOB |
| (38). | 2436U1309F1 | [1] | HYDRAULIC VALVE | KOBASSY, REDUCTION |
