纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (01-002[02]) - FRAME GROUP, UPPER New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
946 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YR52F01080D7 | [5] | RUBBER SEAL | KOB Superseded by part number: YY52F01567D5 |
| 2. | YR52F01086D3 | [1] | RUBBER SEAL | KOB |
| 3. | YT64H01029D7 | [1] | RUBBER | KOB |
| 4. | YT68H01031P1 | [1] | GROMMET | KOB |
| 5. | YT32H01066P1 | [1] | GROMMET | KOB |
| 6. | YT13E01120P1 | [1] | GROMMET | KOB |
| 7. | PH13E01071P1 | [2] | GROMMET | KOB |
| 8. | 2420Z1234 | [1] | GROMMET | KOB |
| 9. | YT52F01189P1 | [2] | INSULATION | KOB |
| 10. | YT52F01266P1 | [1] | GROMMET | KOB |
| 11. | LF03H01020P1 | [1] | GROMMET | KOB |
| 12. | LF03H01019P1 | [1] | GROMMET | KOB |
| 13. | LF52F01127P1 | [1] | INSULATION | KOB, Serial Range: LF06-04501-LF06-04543 Superseded by part number: LF52F01129P1 |
| 13. | LF52F01129P1 | [1] | INSULATION | KOB, Start Serial: LF06-04544 |
| 14. | LF52F01107P1 | [1] | INSULATION | KOB |
| 15. | YT52F01258P1 | [1] | INSULATION | KOB |
| 16. | YN64H01068D3 | [2] | RUBBER | KOB |
| 17. | YR52F01080DE | [2] | RUBBER SEAL | KOB Superseded by part number: YY52F01567D5 |
| 18. | PA03H01044D3 | [1] | RUBBER | KOB, Start Serial: LF06-04544 |
| 19. | YT64H01029D5 | [1] | RUBBER | KOB |
| 20. | YT64H01029DD | [1] | RUBBER SEAL | KOB, Serial Range: LF06-04501-LF06-04543 |
| 20. | YT64H01029DG | [1] | , Start Serial: LF06-04544 | |
