纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (01-003[00]) - COUNTERWEIGHT INSTALLATION New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
685 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT60C00021F1 | [1] | | |
| 1. | YT60C00016P1 | [1] | COUNTERWEIGHT | KOB Superseded by part number: YT60C00026P1 |
| 2. | YT60C00017F1 | [1] | COUNTERWEIGHT | KOBInstal |
| 3. | ZS18C20130 | [3] | CAPSCREW,Hex, M20 x 130mm | KOBSCREW Cap, Serial Range: LF06-04501-LF06-04542 |
| 4. | HY26Y21050G4 | [3] | WASHER | KOB, Serial Range: LF06-04501-LF06-04542 |
| 4. | HY26Y21050G5 | [3] | WASHER | KOB, Start Serial: LF06-04543 |
| 5. | YT60C01006D1 | [3] | SHIM,3.2mm Thk | KOB(3.2) |
| 6. | YT60C01006D2 | [3] | SHIM,20.mm Thk | KOB(2.0) |
| 7. | YT60C01006D3 | [3] | SHIM,1.0mm Thk | KOB(1.0) |
| 8. | LE60C01028P1 | [2] | PLATE | KOB |
| 9. | YT60C01007P1 | [3] | PLUG | KOB |
| 10. | YT60C00018F1 | [1] | COUNTERWEIGHT | KOBAssy. |
| 11. | YT60C01029P2 | [1] | INSULATION | KOB |
| 12. | YT60C01030P2 | [1] | INSULATION | KOB |
| 13. | YT60C01031P2 | [1] | INSULATION | KOB |
| 14. | YT60C01037P1 | [1] | INSULATION | KOB |
| 15. | YT60C01038P1 | [1] | INSULATION | KOB Superseded by part number: YA60C01005P1 |
