纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (01-004[02]) - CYLINDER INSTALLATION New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
550 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | LF02B00009F1 | [1] | CYLINDER | KOBInstal |
| 2. | LF02B01019P3 | [1] | PIN | KOB |
| 3. | LF02B01026P2 | [1] | PIN | KOB |
| 4. | LF02B01027P1 | [1] | PLATE | KOB |
| 5. | ZS18C10025 | [2] | SCREW,Hex, M10 x 25mm | KOBCap |
| 6. | ZS18C12025 | [2] | SCREW,Hex, M12 x 25mm | KOBCap |
| 7. | 2418T17895 | [1] | WASHER | KOB |
| 8. | ZW16H10000 | [2] | WASHER | KOB |
| 9. | ZW16H12000 | [1] | WASHER | KOB |
| 10. | ZW26X12000 | [1] | WASHER | KOB |
| 11. | LF02B01029D1 | [3] | SHIM | KOB(0.5) |
| 12. | LF02B01029D2 | [3] | SHIM | KOB(0.9) |
| 13. | LF02B01029D3 | [3] | SHIM | KOB(0.9) |
| 14. | LF01V00007F1 | [1] | HYDRAULIC CYLINDER | KOBSwing |
