纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (01-007[01]) - RADIATOR INSTALLATION New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
434 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT05P00020F1 | [1] | | |
| 1. | YT05P01229F2 | [1] | FRAME | KOBAssy. |
| 2. | YT05P01189P1 | [2] | RUBBER SLEEVE | KOB |
| 3. | YT05P01107P1 | [2] | RUBBER SLEEVE | KOB |
| 4. | YT05P01108P1 | [2] | RUBBER SLEEVE | KOB |
| 5. | YT05P01255P1 | [1] | RUBBER SLEEVE | KOB |
| 6. | YT05P01254P1 | [1] | RUBBER SLEEVE | KOB |
| 7. | YT05P01111P1 | [1] | INSULATION | KOB |
| 8. | YT05P01112P1 | [1] | INSULATION | KOB |
| 9. | YT05P01113P1 | [1] | RUBBER SLEEVE | KOB |
| 10. | 2427P1836D35 | [1] | WEATHERSEAL STRIP | KOB |
| 11. | YT05P01235P1 | [1] | INSULATION | KOB |
| 12. | YJ13E01014P1 | [2] | GROMMET | KOB |
| 13. | YT05P01230P2 | [1] | FRAME | KOB |
