纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (01-007[02]) - RADIATOR INSTALLATION New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
387 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YT05P00017F1 | [1] | RADIATOR | KOBAssy. |
| 2. | YT05P00021F1 | [1] | RADIATOR | KOB |
| 3. | YT05P01080P1 | [1] | INTERCOOLER | KOBAir |
| 4. | YT53V00002P1 | [1] | OIL COOLER | KOB |
| 5. | YT05P01232F1 | [1] | SHROUD | KOBAssy., Radiator |
| 6. | YT05P01233P1 | [1] | SHROUD | KOB |
| 7. | YT05P01125P1 | [2] | RUBBER SLEEVE | KOB |
| 8. | YT05P01172F1 | [1] | COVER ASSY | KOB |
| 9. | YT05P01173P1 | [1] | COVER | KOB |
| 10. | YT05P01126P1 | [1] | RUBBER SLEEVE | KOB |
| 11. | YT05P01133P1 | [1] | RUBBER SLEEVE | KOB |
| 12. | YT05P01174F1 | [1] | COVER ASSY | KOB |
| 13. | YT05P01177P1 | [1] | COVER | KOB |
| 16. | YT05P01101P1 | [1] | INSULATION | KOB |
| 17. | YT05P01102P1 | [1] | INSULATION | KOB |
| 18. | YT05P01103P1 | [4] | RUBBER SEAL | KOB |
| 19. | YT05P01104P1 | [1] | RUBBER SLEEVE | KOB |
| 20. | ZM73C08016 | [8] | BOLT,M8x16mm - Course Thread | KOBSems |
| 21. | ZM73C08020 | [8] | BOLT,M8x20mm - Course Thread | KOBSems |
| 22. | ZM73C10025 | [4] | BOLT,M10x25mm - Course Thread | KOBSems |
| 23. | YT05P00019F1 | [1] | RADIATOR | KOBInstal |
| 24. | YT05P01168P1 | [1] | STAY | KOB |
| 25. | ZM73C12030 | [6] | BOLT,M12x30mm - Course Thread | KOBSems |
