神钢零件查询(MD140C) - EXCAVATOR BTW YPU0301 - YPU0500 (1/80-12/06) (12-008) - VALVE ASSY, BYPASS (INDEPENDENT TRAVEL) (2436U2584F1) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
652 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2436U2584F1 | [1] | X | KOBBYPASS CONSISTS OF THE FOLLOWING PARTS |
| 101. | NSS | [1] | NOT SOLD SEPARAT | CONCASING |
| 102. | NSS | [1] | NOT SOLD SEPARAT | CONCASING |
| 103. | NSS | [1] | NOT SOLD SEPARAT | CONCASING |
| 151. | 2436U741S462 | [8] | PLUG | KOB |
| 153. | ZE82T04000 | [1] | PLUG | KOB1/4" PT |
| 161. | ZD12P02100 | [2] | O-RING,2.4mm Thk x 20.8mm ID, 90 Duro | KOBO-Ring -- ID 20.80 ± 0.23 x OD 25mm |
| 162. | ZD12P01600 | [2] | O-RING | KOBID 15.80 ± 0.20 x OD 20mm |
| 163. | ZD12P00800 | [2] | O-RING,1.9mm Thk x 7.8mm ID, 90 Duro | KOBID 7.8mm x OD 9.7mm |
| 164. | ZD12G02500 | [2] | O-RING,24.40mm ID x 30.60mm OD x 3.10mm | KOBID 24.4 ± 0.25 x OD 30mm |
| 165. | ZD12P01400 | [1] | O-RING | KOBID 13.80 ± 0.19 x OD 18mm |
| 171. | ZS23C10110 | [5] | SCREW,Hex Socket Head, M10 x 110mm | KOBM10x1.50x110mm |
| 173. | ZS23C10090 | [1] | CAPSCREW M10x1.50x90mm | CAPSCREW M10x1.50x90mm |
| 301. | 2436U2584S301 | [1] | SPOOL BYPASS | SPOOL BYPASS |
| 302. | 2436U2584S302 | [2] | SPOOL | |
| 303. | 2436U2584S303 | [2] | SPOOL | |
| 304. | 2436U2584S304 | [1] | SPOOL, BYPASS | |
| 321. | 2436U2584S321 | [1] | SPRING | KOB |
| 322. | 2436U2584S322 | [1] | SPRING | KOB |
| 323. | 2436U1444S323 | [4] | SPRING | KOB |
| 325. | 2436U2584S325 | [1] | SPRING | KOB |
| 326. | 2436U2584S326 | [1] | SPRING | KOB |
| 331. | 2436U1444S331 | [2] | ROD | ROD |
| 332. | 2436U1444S332 | [4] | ROD | |
| 351. | 2436U1444S351 | [2] | PLUG | KOBPLUG |
| 352. | 2436U1832S651 | [8] | PLUG | KOBM18x1.5mm |
| 353. | 2436U585S651 | [2] | PLUG | KOB Superseded by part number: YT30V00009S153 |
| 354. | 2436U368S151 | [1] | PLUG | KOB |
| 361. | ZD12P02400 | [2] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
| 362. | ZD12P01600 | [8] | O-RING | KOBID 15.80 ± 0.20 x OD 20mm |
| 363. | ZD12P01000 | [2] | O-RING | KOBID 09.80 ± 0.17 x OD 13mm |
| 364. | ZD12P01100 | [1] | O-RING | KOBID 10.8mm x OD 13.2mm |
| 371. | ZS23C06045 | [4] | CAPSCREW,Hex Socket Head, M6 x 45mm | KOBSCREW M06x1.0x45mm |
| 372. | ZS23C06020 | [3] | SCREW,Hex Socket Head, M6 x 20mm | KOBM06x1.0x20mm Superseded by part number: ZS28C06020 |
| 511. | 2483U172S19 | [2] | BALL | KOB |
| 541. | 2436U1165S541 | [1] | SEAT/SLOT | KOB |
| 542. | 2436U1273S541 | [1] | SEAT | |
| 771. | 24100U1156S891 | [1] | NAME-PLATE | |
