纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (01-009[02]) - HYDRAULIC LINES, CYLINDER New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
504 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | LF42H01045P1 | [1] | TUBE | KOB |
| 2. | 2444R1117D090 | [1] | HOSE,6.40mm ID x 900mm L | KOB Superseded by part number: HX21E04090DY |
| 3. | ZA23F18008 | [1] | HYD CONNECTOR | KOB |
| 4. | ZA33F22008 | [1] | ELBOW,M30 x 1.5 ORB x 1/2" NPT | KOB |
| 5. | ZH32Z04000 | [1] | ELBOW | KOB |
| 6. | ZG91S02000 | [2] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB |
| 7. | ZD12P01800 | [2] | O-RING | KOB |
| 8. | PY01P01043D2 | [4] | CABLE TIE,4.60mm W x 202mm L | KOB Superseded by part number: YT50C01100P1 |
| 9. | LF42H01055P1 | [1] | BAND | KOB |
| 10. | YR42H01116P1 | [1] | BAND | KOB |
| 11. | YR43H01003P1 | [1] | CLAMP | KOB |
| 12. | ZS18C10030 | [2] | SCREW,Hex, M10 x 30mm | KOBCap |
| 13. | ZS18C10050 | [1] | SCREW,Hex, M10 x 50mm | KOBCap |
| 14. | ZW16H10000 | [1] | WASHER | KOB |
| 15. | ZW26X10000 | [2] | LOCK WASHER | KOB |
| 16. | 2418R676D14 | [1] | TUBE | KOB |
