纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (01-010[00]) - AIR CLEANER ASSEMBLY New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
477 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT11P00008F1 | [1] | Air | |
| 1. | YT11P00009F2 | [1] | AIR CLEANER | KOB |
| 2. | YT11P00009S001 | [1] | BODY | KOBAssy. |
| 3. | YT11P00009S007 | [1] | ELEMENT | KOBAssy., Inner Superseded by part number: 86982523 |
| 4. | YT11P00009S002 | [1] | ELEMENT | KOBAssy., Outer Superseded by part number: 86982522 |
| 5. | YT11P00009S003 | [1] | COVER ASSY | KOB |
| 6. | YT11P00009S004 | [1] | CONTROL VALVE | KOBAssy. |
| 7. | YT11P00009S005 | [1] | INDICATOR | KOB |
| 8. | YT11P01023P2 | [1] | BRACKET | KOB |
| 9. | YT11P01017P1 | [1] | AIR HOSE | KOB |
| 10. | YT11P01018P1 | [1] | AIR HOSE | KOB |
| 11. | YT11P01019P1 | [1] | AIR HOSE | KOB |
| 12. | YT11P01021P1 | [1] | TUBE | KOB |
| 13. | ZM73C08016 | [2] | BOLT,M8x16mm - Course Thread | KOBSems |
| 14. | ZM73C10025 | [2] | BOLT,M10x25mm - Course Thread | KOBSems |
| 15. | ZC16X05100 | [1] | CLIP | KOB |
| 16. | ZC16X06100 | [2] | CLIP | KOB |
| 17. | ZC16X09100 | [3] | CLIP | KOB |
