神钢零件查询(MD180LC) - EXCAVATOR ASN YG0647 (1/80-12/06) (01-003) - TANK ASSY, HYDR Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
504 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J5993F4 | [1] | TANK ASSY, HYDR | |
| 2. | 2446R307F2 | [1] | STRAINER ELEMENT | KOB |
| 2-1. | 2446R307S1 | [1] | STRAINER ASSY. | KOB Superseded by part number: YN50V00002S001 |
| 2-3. | 2446R110S2 | [1] | HOLDER | KOBHOLDER |
| 2-4. | ZN11C10008 | [2] | NUT | KOBM10x1.50mm Superseded by part number: ZN18C10008 |
| 2-5. | 2446R110S6 | [1] | SPRING | KOB |
| 2-6. | 45Z91D6 | [1] | O-RING | KOBID 97.79 ± 0.38 OD 108.45mm |
| 2-7. | 2446R110S5 | [1] | SCREW | KOB |
| 3. | 2418T12123 | [1] | FLANGE | KOB |
| 4. | 2418P9988 | [1] | FLANGE | KOB |
| 5. | ZD11G16500 | [1] | O-RING,164.30mm ID x 175.70mm OD x 5.70mm | KOBID 164.30 ± 1.30 x OD 175.7mm |
| 6. | ZD11G19000 | [1] | O-RING,189.30mm ID x 200.70mm OD x 5.70mm | KOBID 189.30 ± 1.47 x OD 200mm |
| 7. | R36P0002 | [1] | ELEMENT | KOB Superseded by part number: YN50V00001P1 |
| 8. | 2446R131 | [1] | VALVE | KOB |
| 9. | 2436Z308S1 | [1] | SPRING | KOB |
| 10. | 2446U228F1 | [1] | BREATHER | KOB |
| 10-1. | 2446U228S1 | [1] | CASE | KOB |
| 10-2. | 2446U228S2 | [1] | STRAINER ELEMENT | KOB Superseded by part number: 2446R133 |
| 10-3. | 2446U228S3 | [1] | GASKET | KOB |
| 10-4. | 2446U228S4 | [3] | SCREW | KOB |
| 10-5. | ZD11P03200 | [1] | O-RING | KOB |
| 10-6. | 2446U228S6 | [1] | VALVE | KOB |
| 10-7. | 2446U228S7 | [1] | COVER | KOB |
| 10-8. | 2446U228S8 | [1] | ELEMENT | KOB |
| 10-9. | 2446U228S9 | [1] | COVER | KOB |
| 10-10. | 2446U228S10 | [1] | SCREW | KOB |
| 10-11. | 2446U228F11 | [1] | SPANNER | |
| 10-12. | 2446U228S12 | [1] | LABEL | KOB |
| 18. | 2427T826 | [1] | PLATE | KOB |
| 19. | ZE82T08000 | [1] | PLUG | KOB1/2" PT |
| 23. | ZS18C12025 | [4] | SCREW,Hex, M12 x 25mm | KOBM12x1.75x25mm |
| 24. | ZS13C08018 | [4] | SCREW | KOBM08x1.25x18mm Superseded by part number: ZS18C08020 |
| 25. | ZW22X16000 | [4] | WASHER, LOCK | KOBID 16 x OD 28.0 x Th 4.0mm |
| 26. | ZW26X12000 | [8] | LOCK WASHER | KOBID 12 x OD 21 x Th 3.0mm |
| 27. | ZW22X08000 | [4] | LOCK WASHER | KOBID 08 x OD 15.4 x Th 2.0mm Superseded by part number: 83990583 |
| 28. | R16T0152D2 | [4] | WASHER | KOBFlat -- ID 17 x OD 30 x Th 3.2mm |
| 29. | ZW11X08000 | [4] | WASHER | KOBID 09 x OD 17 x Th 1.6mm Superseded by part number: ZW16X08000 |
| 31. | 2427J1312D1 | [1] | TANK, HYDR | |
| 32. | 2489R293F1 | [1] | LEVEL GAUGE | KOB Superseded by part number: YN58S00009F1 |
| 32-1. | 2489R173S1 | [1] | GAUGE | KOB |
| 32-2. | 2489R174S3 | [2] | BOLT | KOBSpecial -- M10x1.50x40mm Long |
| 32-3. | 2489R174S2 | [2] | BLOCK | KOBGAUGE, LEVEL |
| 32-4. | ZD11P01800 | [4] | O-RING | KOBID 17.80 ± 0.21 x OD 22mm |
| 32-5. | ZD11P01000 | [4] | O-RING | KOBID 9.8 ± 0.17 x OD 13.6mm |
| 33. | 2446U215F1 | [1] | FILTER, DRAIN | FILTER, DRAIN |
| 33-1. | 2446U215S01 | [1] | CONTAINER | KOB |
| 33-2. | 2446U175S2 | [1] | VALVE | KOB |
| 33-3. | 2446U175S3 | [1] | SPARE PART | HITCARTRIDGE Superseded by part number: 2446U215S5P |
| 34. | 2444T2517 | [1] | ELBOW | ELBOW |
| 35. | 2444Z2322 | [1] | TEE | KOB |
