神钢零件查询(MD180LC) - EXCAVATOR ASN YG0647 (1/80-12/06) (01-002) - COUNTER-WEIGHT ASSY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
208 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100N2898F2 | [1] | COUNTER-WEIGHT ASSY | |
| 3. | R16T0152D4 | [4] | WASHER | KOBFlat -- ID 24 x OD 44 x Th 4.5mm |
| 4. | 24100N2899F2 | [1] | COUNTER-WEIGHT ASSY | |
| 4-2. | 2416Z441 | [1] | INSULATOR | INSULATOR |
| 4-3. | 2422J1671 | [1] | COUNTER-WEIGHT | |
| 4-4. | 2416Z435D2 | [2] | RUBBER SLEEVE | KOBCUSHION |
| 4-5. | ZS41C05016 | [4] | SCREW,M5 x 16mm | KOBM05x0.8x16mm |
| 6. | 2420Z933D4 | [4] | SCREW | KOB |
| 9. | 2418T12306D2 | [2] | SHIM | KOB0.6 |
| 10. | 2418T12306D3 | [2] | SHIM | KOB0.4 |
| 11. | 2418T12306D6 | [2] | SHIM | KOB1.6 |
