纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (01-011[00]) - MUFFLER ASSEMBLY New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
136 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT12P00012F1 | [1] | | |
| 1. | YT12P00013P1 | [1] | MUFFLER | KOB |
| 2. | YT12P01054P2 | [1] | BRACKET | KOB |
| 3. | YT12P01030P1 | [1] | TUBE | KOBExhaust |
| 4. | YT12P01052P1 | [1] | TUBE | KOBExhaust |
| 5. | YT12P01031P1 | [1] | CLAMP | KOBAssy. |
| 6. | HR91C08000GK | [2] | CLAMP | KOBU-Bolt |
| 7. | HX11Y07066DX | [1] | HOSE ASSY. | KOB Superseded by part number: HX11Y07100DX |
| 8. | ZM73C12020 | [1] | BOLT,M12x20mm - Course Thread | KOBSems |
| 9. | ZM73C10025 | [6] | BOLT,M10x25mm - Course Thread | KOBSems |
| 10. | ZS18C10035 | [2] | SCREW,Hex, M10 x 35mm | KOBCap |
| 11. | ZW16P10000 | [2] | WASHER | KOB |
| 12. | ZW16P08000 | [3] | WASHER | KOB |
| 13. | ZN18C10008 | [2] | NUT | KOB |
| 14. | ZN18C08007 | [11] | NUT | KOB |
| 15. | YB12P01011P1 | [1] | CLIP | KOB |
| 16. | ZC16X01200 | [1] | CLIP,8mm - 15mm | KOB |
| 17. | YT12P01061P1 | [1] | BRACKET | KOB |
| 18. | ZM73C06025 | [2] | BOLT,M6x25mm - Course Thread | KOBSems |
| 19. | ZM73C06016 | [2] | BOLT,M6x16mm - Course Thread | KOBSems |
| 20. | ZM73C08016 | [1] | BOLT,M8x16mm - Course Thread | KOBSems |
| 21. | ZS18C06012 | [2] | SCREW,Hex, M6 x 12mm | KOBCap |
| 22. | ZW16H06000 | [2] | WASHER | KOB |
