神钢零件查询(MD180LC) - EXCAVATOR ASN YG0647 (1/80-12/06) (10-003) - TOOL ASSY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
792 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100N2979F13 | [1] | TOOL ASSY | |
| 1. | ZT12A55000 | [1] | SPECIAL WRENCH | KOBSpanner -- 55mm |
| 2. | ZT12A41000 | [2] | ADJUSTING WRENCH | KOBSpanner, 41mm |
| 3. | ZT12A36000 | [1] | SEAT BACK | KOBSpanner, 36mm |
| 4. | ZT12A27000 | [1] | HEATER | KOB27mm |
| 5. | ZT12A19000 | [1] | GEAR | KOBSpanner, 19mm |
| 6. | ZT12A17000 | [1] | PLUG | KOBSpanner, 17mm |
| 7. | ZT12A10000 | [1] | PLUG | KOBSpanner, 10mm |
| 8. | 2421Z294 | [1] | BLOCK DRIVER | KOBDRIVER Screw, 165mm Long |
| 9. | ZT31B13250 | [1] | HANDLE | KOB |
| 10. | ZT31D13150 | [1] | BAR | KOB |
| 11. | ZT31A17000 | [1] | SOCKET | KOB |
| 12. | ZT31A19000 | [1] | SOCKET | KOB |
| 13. | ZT31A22000 | [1] | SOCKET | KOB |
| 14. | ZT31A27000 | [1] | SOCKET | KOB |
| 16. | ZT22A06000 | [1] | KEY, SCREW 06mm | KEY, SCREW 06mm |
| 17. | ZT22A08000 | [1] | KEY | KOBScrew -- 08mm |
| 18. | ZT22A14000 | [1] | KEY | KOB14mm |
| 20. | ZT12D20000 | [1] | WRENCH, ADJUST 24mm Maximum | WRENCH, ADJUST 24mm Maximum |
| 21. | 2421T8 | [1] | TIGHTENER | KOB |
| 22. | ZT71A15000 | [1] | HAMMER | KOB |
| 25. | ZT51A15000 | [1] | PLIERS | KOB |
| 26. | 2421R127 | [1] | SPECIAL WRENCH | KOB |
| 28. | 2444Z2329 | [1] | HOSE | KOB |
| 29. | 2421R154 | [1] | GREASE GUN | KOB Superseded by part number: EAPN17125A |
| 41. | B16T0442D2 | [1] | SHIM,130mm OD x 72mm ID x 1.6mm Thk | KOBID 72 x OD 130 x Th 1.6mm |
| 42. | B16T0442D4 | [4] | SHIM,82mm ID x 150mm OD x 1.6mm Thk | KOBID 82 x OD 150 x Th 1.6mm |
| 43. | B16T0442D5 | [1] | SHIM,130mm OD x 72mm ID x 2.3mm Thk | KOBID 72 x OD 130 x Th 2.3mm |
| 44. | B16T0442D6 | [1] | SHIM,150mm OD x 82mm ID x 2.3mm Thk | KOBID 82 x OD 150 x Th 2.3mm |
| 45. | B16T0442D1 | [3] | SHIM,130mm OD x 72mm ID x 1.2mm Thk | KOBID 72 x OD 130 x Th 1.2mm |
| 46. | B16T0442D3 | [4] | SHIM,150mm OD x 82mm ID x 1.2mm Thk | KOBID 82 x OD 150 x Th 1.2mm |
| 47. | B16T0442D28 | [4] | SHIM,150mm OD x 82mm ID x 2.0mm Thk | KOBID 82 x OD 150 x Th 2.0mm |
| 48. | B16T0442D29 | [1] | SHIM,130mm OD x 72mm ID x 2.0mm Thk | KOBID 72 x OD 130 x Th 2.0mm |
| 49. | ZT31A24000 | [1] | SOCKET | KOB |
| 63. | 4027R1D2 | [1] | CAM | CAM |
